Vario Indicator Unit
. . Digital indicators
The analog indicator's main page features two numerical indicators.
Each of these indicators is formatted in the same way. On the far-left, the name of the indicator
is displayed, noting which ight parameter the indicator is showing. Next, with larger fonts, the
actual value is shown, with the value unit to the right of the shown value. These indicators are
the only pilot-adjustable elds on this page.
The digital indicators are set in the main unit setup, as described in the Indicators setup menu.
. . Status indicators
. . . Wind indicator
The wind is indicated in on the left of the central part of the screen. Unlike the digital vario
indicator, no green/black arrow is present for showing relative wind direction. The wind is only
shown in speed and absolute direction.
The wind is being calculated both in circling and in straight ight. It will update at all times and
no settings are required.
. . . Flarm status indicator
Is represented with a red Flarm symbol, depicted with Flarm status indicator icon. If the Flarm
icon is present, the device has an established connection with a Flarm device. On how to get
more info from the Flarm device, check the Info page section. For information about Flarm
objects and the Flarm radar page, check the Flarm radar page.
. . . GPS status indicator
The GPS status indicator indicates whether or not the device has a valid GPS lock. Under valid
GPS lock, a connection to at least four satellites is required.
Figure
Device manual
Figure 6. Flarm status indicator icon
. GPS signal is not valid
Document name:
Document revision:
Figure 8. GPS signal is
valid
