LX k
Basic operation
.

User input

The LX k was envisioned to be simple and intuitive to use. There are two buttons and two
push-rotary buttons mentioned in the previous sub-section.
The LX k can also be commanded by an LX Joy. Learn more in the LX Joy section of this
manual.
. . Right push-rotary knob (PAGES)
The right push-rotary is used for the following functions:
• Changing between primary pages, clockwise for next, counter-clockwise for previous.
• Scrolling, turn clockwise for moving down, right or for choosing larger values, counter-
clockwise for moving up, left or cahnging by smaller values.
• Turning while being pressed, acts as noted above, by
• Pressing, acts as 'Con rm', 'Enter'
• Holding it, while in a navigation page, will open the 'NavBox select' sub-page
. .

Left push-rotary knob (ZOOM)

The left push-rotary is used for the following functions:
• Zooming, turn clockwise to zoom in, counterclockwise to zoom out
• Scrolling, moving down, right or for choosing larger values, clockwise for moving down
or changing by larger values, by
• Pressing, acts as 'Cancel', 'Exit'
• Turning while being pressed, acts as noted above, by
. .

Right push button (MC)

The right push button is used for opening the MC sub-page, which gives us the MC sub-page,
while in any primary page. This page can be used for setting, Volume, MacCready, Ballast,
Bugs, QNH and Brightness.
. .

Left push button (BOX)

The left push button is used for changing the NavBox lines on all four navigation pages.
Holding it will open the 'NavBox select' sub-page, and pressing it will slide through the three
dedicated NavBox lines and hide it with the fourth click.
