Advanced operation
• Start (S) - The starting point of your task
• n-number of intermediate points
• Finish (F) - Finish line
• Landing (L) - Does not have to be set, is navigated to after the nish line has been passed,
can not be deleted
By default, the task edit page shows only four points: Take-off, Start, Finish and Landing.
Selecting the Take-off and Landing point, will offer the option of choosing a point from the
turnpoint or airport list, in the same way as described in the Turnpoint navigation page.
Selecting the Start point will offer the option of choosing the navigation point, in the same
manner as already noted for the Take-off and landing location before. Additionally, the options
for Go to and Edit zone option are presented for the Start point.
If you wish to add additional navigation points, you need to select the Finish line point, where,
in addition to the options offered for the star line, option for inserting a turnpoint or airport will
be offered.
Choosing one of these options will insert an additional navigation point above the nish point.
Similarly, when choosing one of the added navigation points, selecting the 'insert turnpoint' or
airport will place the new navigation point above the chosen one.
Additionally, the nish line has the options of setting a nish altitude of
line, which, in case the nish point altitude is more than
the tow plane, the device will navigate and calculate nal glide to the altitude
release from the tow plane. This condition is usually required for FAI record and badge ights.
Device manual
Figure . Navigation point action selection
Public
Document name:
Document revision:
m below starting
m below the point of release from
LX KUM
R
m below the
