LX k

Advanced operation

Primary pages overview
This section will cover the complete specter of operations possible on LX
There are primary pages on the LX
right push-rotary knob (PAGES). The pages are listed as follows:

. Turnpoint navigation page

. Airport navigation page

. Task navigation page

. Nearest landable navigation page

. Thermal assistant page
6. Flarm radar page
. AHRS page
8. G-force page
. Info page
. Logbook/Flight statistics page
. Airspace page
. Setup page
. Navigation pages
The LX k offers
turnpoint, airport, over a task and to the nearest landable point.
The basic layout of each navigation page is the same. In the top of the page, we can see the
header. Below the header, we can see the moving map, the wind indicator on the left and the
nal glide indicator on the right. Above the nal glide indicator, a zoom scale is positioned and
in the bottom of the page, the NavBox line is positioned.
Pressing the left push-rotary knob will show additional info for the point we're currently
navigating to on the tunpoint, airport and nearest landable page and open additional task
options on the task navigation page. Rotating the left push-rotary will change the zoom level.
Pressing the left push button will initiate NavBox line commands. A short press will change
between different NavBox lines, and a long press will initiate the 'Select NavBox' dialog.
Device manual
Advanced operation
separate navigation pages, giving the pilot simultaneous navigation to a
Document name:
Document revision:
k. You can scroll between these pages by using the
Public
LX KUM
R
k's primary pages.
