Advanced operation
. . . The Final glide indicator
The Final glide indicator is an indicator located opposite of the wind indicator, on the far right
of the map, above the NavBox line. It displays the Final Glide for the set MC value. The MC
value is displayed above the Final Glide value, in white lettering. If you are within nal glide,
and your arrival altitude is positive, the nal glide will be written in green. If you are not within
nal glide, your nal glide will be written in red.
Once nal glide is established, the LX
speaker, stating: 'Final glide established'.
. . . The NavBox line
In the lower part of the screen a NavBox line containing
set-up up to three separate NavBox lines with his/her own NavBox preferences. Usually pilots
set one NavBox line for aerodrome gliding, one for racing tasks and one for AAT tasks.
Pressing the (BOX) push button will swipe through these NavBox lines. If the (BOX) push
button is pressed after the third line of navboxes, the navbox line will disappear, giving the pilot
a larger and clearer representation of the map. Press the (BOX) push button again, for the
NavBox line to reappear.
Holding the (BOX) push button, or holding the (PAGES) push-rotary knob for three seconds will
start the 'Select NavBox' procedure. The navbox's black background will turn red, and the pilot
can now choose which navbox he would like to change. Once the desired navbox position has
been chosen, he can press enter (PAGES) and a list of available NavBoxes will appear. From
the list, he can select a navbox he wishes and con rm it by pressing enter.
The following NavBoxes are available:
• UTC time
• Local time
• Flight time
• Altitude
• IGC altitude
• Flight level
• Density altitude
• GPS altitude
• Height AGL
• Elevation
• Alt. QNH [ft]
• Vario
• Vario AVG
• Vario netto
Since most of the indicators are self-explanatory, we will cover the ones that are not.
Device manual
k will notify you with a Voice noti cation over the
• Vario relative
• TAS
• IAS
• Ground speed
• True track
• Distance
• Final glide
• Speed to y
• Bearing
• Task time elapsed
• Task time left
• Current ef ciency
• Require ef ciency
• Thermal max
Public
Document name:
Document revision:
NavBoxes is shown. The pilot can
• Thermal average
• Eff. thermal avg.
• Thermal gain
• Circling radius
• OAT
• ENL
• G-force
• Flap position
• Rec. ap position
• Phase of ight
• No of landings
• Last landing time
