Basic operation
.

Device interface

The LX k features two push buttons and two push-rotary knobs for pilot-device communi-
cation. The front side of the device, represented by gure , shows the LX
interface.
On the front plate, we can see the following items:
. M x6 Phillips head screw
. LX k display
. Left push button (BOX)
. microSD card reader
We will name the two main push buttons and two main push-rotary buttons by their function
(ZOOM, MC, BOX, PAGES). The push-rotary knob on the LX
function - (VOL).
Device manual
Figure . LX k front plate interface
Public
Document name:
Document revision:
. Left push-rotary knob (ZOOM)
6. M x6 Phillips head screw
. Right push button (MC)
8. Right push-rotary knob (PAGES)
k indicator will be named by it's
LX KUM
R
k's user input
