5.3 Transport Layer Control
The camera's tap geometry should match with that of frame grabber, and inconsistent parameters
may lead to image exception.
CameraLink Line Scan Camera
Description
You can view and set the device resolution, image reverse
function, pixel format, region of interest, test pattern, etc.
You can view and set the device acquisition mode, line rate,
trigger mode, exposure mode, etc.
You can view and set the device gain, black level, Gamma
correction, etc.
You can view and set the device color transformation related
parameters like hue and saturation.
You can view the Look-Up Table (LUT) and set its index and
value.
You can set encoder control to convert source signal of external
trigger into internal signal.
You can set frequency converter control to convert external
signal of different frequencies into internal signal.
You can set shading correction to correct shade.
You can set the different input and output signals.
You can set the parameters of transport layer of the device.
You can save or load the device's parameters. You can set the
default parameter when running the client software.
