Parameter
BalanceWhiteAuto
BlackLevel
BlackLevelEnable
GammaAbsVal
CameraLink Line Scan Camera
Command
r DigitalShift
w BalanceWhiteAuto
r BalanceWhiteAuto
w BlackLevel x
r BlackLevel
w BlackLevelCtrl x
r BlackLevelCtrl
w GammaAbsVal
x×100+y
r GammaAbsVal
User Manual
·
Value
value and disable
digital shift
z: write serial port
value and enable
digital shift
y=x × 511 /6 +511
z=x × 511/6+66047
When value is larger
than 65536, digital
shift is enabled.
0—off
1—continue
2—once
0—off
1—continue
2—once
x: 0-4095
x:
0—disable
1—enable
x: game value
y:
0x20000—represents
sRgb
0x10000—represents
User
69
Description
shift is -6 to 6.
Eg. w DigitalShift 512. It
means setting gain as 0.01,
and disabling digital shift.
Eg. w DigitalShift 66048. It
means setting gain as 0.01,
and enabling digital shift.
Read digital shift.
If digital shift is enabled, read
z and x =(z-66047) × 6/511.
If digital shift is disabled, read
y, and x=y × 6/511-6.
Set white balance mode. Eg:
w BalanceWhiteAuto 2.
Read white balance mode.
Set black level. Eg. w
BlackLevel 5.
Read black level.
Set black level enable.
Eg. w BlackLevelCtrl 1.
Read black level enable.
Set Gama value, and
GamaEnable on is availabe.
Eg:
w GammaAbsVal 2 × 100+0 ×
10000.
Read Gamma value.
