the Ethernet TCP/IP network. If you connect directly to one of the Master Nodes
using USB, a modem, or a COM port, you will be able to configure that device but
not any other device.
Lobby Control Unit
(Master Node)
Figure 30. TX3 devices on an Ethernet TCP/IP network.
Notes:
TX3 Emergency Phone Installation and Operation Manual
52
LT-6113 Copyright 2017
Lobby Control Unit
(Master Node)
1 2 3
ABC DEF 1 2
ABC
4 5 6
GHI JKL
MNO 4 5
GHI JKL
7 8 9
PQRS TUV WXYZ
7 8
PQRS TUV
* #
0
* 0
Ethernet Network
In order for a panel to be a Master Node, it must:
•
be IP capable. Panels that are IP capable are usually
denoted by a "-A" at the end of their model names.
•
have a TX3-IP IP Module installed if it is not a Touch
Screen.
Card Access Controller
(Master Node)
3
DEF
6
MNO
9
WXYZ
#
TX3 System
Card Reader A
Card Reader B
Version 2
