Mounting - Mircom TX3 Series Installation And Operation Manual

2.2

Mounting

Attention: To comply with ADA regulations, the call button on TX3-EMER-
•
•
•
•
The emergency phone mounts on the wall. Mount the enclosure right-side up (the
Mircom logo on the door is on the bottom).
You need:
•
1.
2.
3.
4.
5.
TX3 Emergency Phone Installation and Operation Manual
14
LT-6113 Copyright 2017
1S and the keyboard on TX3-EMER-200KS must be no more than
48" (1219 mm) from the ground (forward reach) and 54" (1372
mm) from the ground (side reach). See the ADA Accessibility
Guidelines for more information:
http://www.ada.gov/2010ADAstandards_index.htm
Weight: 10.60 lb (4.8081 kg)
Overall dimensions: Height: 16 5/8" (422 mm) Width: 5 29/32" (150 mm)
Depth: 4 1/2" (114 mm)
Mounting hole diameter: 13/64" (5 mm)
Knockout diameter: 7/8" (22 mm) and 1 1/8" (29 mm)
4 fasteners appropriate for the wall that you are mounting the enclosure on.
Find a suitable location for the enclosure.
Using the enclosure as a template, mark the back mounting locations of the
two keyholes. Ensure that at least one side is over a wall stud.
Remove the enclosure and place the fasteners halfway into the wall into
the marked hole locations.
Place the enclosure onto the fasteners and lower it so that the fasteners fit
in the narrow part of the keyholes.
Screw the other two fasteners into the two remaining holes.
