Installing the Optional MD-921 IP Module

The MD-921 IP Module connects the Emergency Phone to an Ethernet TCP/IP
network. The MD-921 IP Module ribbon cable connects to the P5 connector on
the controller board (see Figure 4 on page 17). This allows you to configure and
monitor the TX3 devices on your system using a computer and an Ethernet
connection.
The IP Module has an RJ-45 connector that connects to the Ethernet network
using a standard Ethernet cable as shown in Figure 15.
Figure 15. IP Module Data and Ethernet Connectors
For a description on how to install the IP Module, see LT-1161 MD-921 IP
Module Installation Instructions.
