4.1

Inputs and Outputs

The Emergency Phone has 5 inputs and 4 outputs. Inputs 4 and 5, and Output 1,
are wired to the following components:
•
•
•
4.2

Correlations

The Configurator has four default correlations.
•
•
•
•
4.3

Program the Buttons

Dial codes 9991 and 9992 are codes used by the Emergency Phone. You must
link these codes with real telephone numbers (or SIP IDs if you are using a VoIP
modem).
To program the Emergency Call Button
1.
2.
3.
TX3 Emergency Phone Installation and Operation Manual
Version 2
LT-6113 Copyright 2017
Input 4: Emergency Call Button
Input 5: Operator Call Button
Output 4: Strobe (optional)
Input 4 (the Emergency Call Button) calls dial code 9991.
Input 5 (the Operator Call Button) calls dial code 9992.
Output 4 (the strobe) flashes when the Emergency Call Button is in use.
Output 4 (the strobe) stops flashing when the call is finished.
Connect to the Emergency Phone. See Chapter 3 on page 33.
In the Job tree, click Residents.
Double-click Emer Red Buttn.
Programming
