3.3.1

Connect to an existing TX3 network

1.
2.
3.
Figure 17. Add Panel
4.
5.
6.
7.
8.
9.
TX3 Emergency Phone Installation and Operation Manual
Version 2
LT-6113 Copyright 2017
Open the TX3 Configurator.
Open the job for your network.
Click Edit > Add Panel.
The Add Panel window appears.
In the Label field, type a name for the Emergency Phone.
In the Address menu, select the RS-485 address of the Emergency Phone.
See Section 2.8 on page 23 for instructions on setting the RS-485 address.
In the Panel Model menu, select the model of the Emergency Phone.
Click Add, and then click Close.
The Emergency Phone appears in the Job tree on the left.
Send the job to the TX3 network.
Go to Chapter 4 on page 40 for instructions on programming the
Emergency Phone.
