2.8

Setting the RS-485 Address

Use DIP switches 1-6 to set the RS-485 network address. The individual switches
are numbered 1 to 8 from left to right, and are marked as either ON or OFF. The
first six switches (1, 2, 3, 4, 5 and 6) set the address.
Every TX3 Emergency Phone requires a unique address. The address settings do
not need to be in sequence but it is recommended to assign addresses starting
from 1, using increments of one (for example, 1, 2, 3, 4, and so on). Do not
duplicate addresses.
Note:
DIP switch SW1 is located at the top central portion of the controller board. See
Figure 4 on page 17.
Table 1 shows the SW1 DIP switch settings for each Emergency Phone.
Note:
Note:
Table 1: Emergency Phone SW1 DIP Switch Settings
Emergency Phone Unit
ID #
0 (not allowed as ID 0 is
used for PC ID)
1
2
3
4
5
6
7
8
TX3 Emergency Phone Installation and Operation Manual
Version 2
LT-6113 Copyright 2017
You must set the address even if you are not using RS-485.
One of the networked units with a real time clock, such as Touch
Screen, Emergency Phone or Card Access must have their network
address set to 1.
DIP switch 7 is not used and must be left at the default factory
setting.
For units with and IP Module installed, DIP Switch 8 determines
how the IP address is assigned to the IP Module.
• DIP Switch 8 OFF: The IP address is assigned using a DHCP
server. This is the default factory setting.
• DIP switch 8 ON: The IP address is assigned using the TX3
Configurator software.
Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
OFF OFF OFF
OFF OFF OFF
OFF OFF OFF
OFF OFF OFF
ON OFF OFF
ON OFF OFF
ON OFF OFF
ON OFF OFF
OFF ON OFF
Installation
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
