Table 1: FN Node Components
Code Number
WD-TIMER-FIRE
NU-NCMFIRE-1
FIREOWS-PC-02
FIRE-MON-17
FIRE-MON-21
MIB-OWS-F-0
MIB-OWS-WF-0
MIB-OWS-W-0
MIB-F
MIB-WF
MIB-W
SIB-NET
RPT-F
RPT-WF
RPT-W
INA
PRN-4 or PRN-3
8 IFC Networking—Metasys Intelligent Fire Network
If a network has both a Fire OWS and an INA, use the INA as a
display-only device unless the Fire OWS or Fire-Net NCM fails. In that
case, use the INA as a backup Person-Machine Interface (PMI) device.
See the Intelligent Network Annunciator (INA) Technical Bulletin
(LIT-448193) for more information.
When the INA is applied to an FN that has IFC panel nodes in more than
one building, the keypad of the INA must be disabled to comply with the
UL Listing, which does not allow signal silence commands from the INA
to more than one building.
Repeaters
The UL Listed repeaters extend communication distances between
FN nodes by boosting data signals. For more information, refer to the
Repeaters Technical Bulletin (LIT-448197).
Description
Metasys Fire Watchdog Enclosure with Relay (required for each Fire OWS)
Metasys Fire-Net NCM. This can either be housed in a Fire Watchdog Enclosure or an
EN-EWC35-0 enclosure. See the Universal Packaging Module (UPM) Product Bulletin
(LIT-635044) for details on the enclosure.
Metasys Fire OWS PC with Metasys and Fire OWS Software, Keyboard, and Mouse
Choose from one of the following monitors for each Fire OWS:
17 in. Metasys Fire OWS Monitor
21 in. Metasys Fire OWS Monitor
Choose from the following for use with each Fire OWS and Fire-Net NCM:
Fiber Optic Media Interface Board (MIB)
Fiber Optic/Copper MIB
Copper Wire MIB
Choose from the following for use with each IFC panel and each INA:
Fiber Optic MIB
Fiber Optic/Copper MIB
Copper Wire MIB
Serial Interface Board required for the IFC panel to connect to the MIB.
Fiber Optic Repeater
Fiber Optic/Copper Repeater
Copper Wire Repeater
Intelligent Network Annunciator
Dedicated (required for each Fire OWS) and Optional Printers
