NAE55/NIE55 Installation Instructions
MS-NAE55xx-2, MS-NIE55xx-2
Application
The Network Automation Engine (NAE) and Network
Integration Engine (NIE) are Web-enabled,
Ethernet-based, supervisory devices. Network Automation
Engines (NAEs) and Network Integration Engines (NIEs)
monitor and control networks of field-level building
automation devices, including HVAC equipment, lighting,
security, and fire safety equipment.
typical NAE55 model.
This document describes how to install an NAE55 or
NIE55, which are referred to collectively as NAE55 or
NAE unless specified otherwise.
North American Emissions
Compliance
United States
This equipment has been tested and found to comply with the
limits for a Class A digital device pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when this equipment
is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area may cause harmful interference, in which case the users
will be required to correct the interference at their own
expense.
NAE55/NIE55 Installation Instructions
Canada
This Class (A) digital apparatus meets all the requirements of
the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
Figure 1
shows a
Installation
Follow these guidelines when installing an NAE55:
Parts Included
Materials and Special Tools Needed
Part No. 24-10051-43, Rev. E
Supersedes January 10, 2012
Refer to the
QuickLIT website
for the most up-to-date version of this document.
Transport the NAE55 in the original container to
minimize vibration and shock damage to the NAE55.
Verify that all the parts shipped with the NAE55. The
data protection battery and NAE55 ship together but
are packaged separately.
Do not drop the NAE55 or subject it to physical shock.
Do not open the NAE55 housing (except the data
protection battery compartment). The NAE55 has no
user-serviceable parts inside.
one NAE55
one data protection battery
one installation instructions sheet
one quick start guide
four fasteners appropriate for the mounting surface
(M4 screws - Europe, #8 screws - North America)
two 36 cm (14 in.) or longer pieces of 35 mm DIN rail
(for DIN rail mount applications only)
Release 6.0
Issued January 30, 2013
1
