Cable Manufacturer,
Part Number,
Gauges/Conductors
(Cont.)
Atlas 228-18-1STP-2,
18 AWG,
1 Pair Shielded
Atlas 228-18-1STP-2,
18 AWG,
1 Pair Shielded
Guardian E2582S,
18 AWG,
1 Pair Shielded
Signal, 98281-06-14, 18
AWG,
1 Pair Shielded
Signal, 98281-06-04, 18
AWG,
1 Pair Shielded
Belden 9581,
14 AWG,
1 Pair Shielded
Belden 9575,
16 AWG,
1 Pair Shielded
Belden 9583,
12 AWG,
1 Pair Shielded
ACE Wire 61401SLL, 14
AWG,
1 Pair Shielded
REMEE Products,
NY5145HHIRHPHB,
14 AWG,
1 Pair Shielded
Note: In the event of a power failure at a wire node, the data is not regenerated locally, it is merely
fed through to the next node. Therefore, the total length of wire is the sum of both lengths of
wire between operating nodes. If the total length exceeds the maximum allowable length for
a given threshold, the network may lose communication. Separately powered repeaters may
be employed at each node in a point-to-point series connection to ensure data regeneration.
Manufacturer's
Specifications
2 Nodes/Repeaters
Low Capacitance,
FPL, PVC,
NEC Article 760,
UL 1424
Low Capacitance,
FPL, PVC,
NEC Article 760,
UL 1424
Mid-Capacitance,
FPL, PVC,
NEC Article 760,
UL 1424
Mid-Capacitance,
FPLP, PVC,
NEC Article 760,
UL 1424
Mid-Capacitance,
FPL, PVC,
NEC Article 760,
UL 1424
FPLR,
NEC Article 760,
UL 1424
FPLR,
NEC Article 760,
UL 1424
FPLR,
NEC Article 760,
UL 1424
FPLP
NEC Article 760
FPLP
NEC Article 760
IFC Networking—Metasys Intelligent Fire Network
Permissible Distance in Feet for Each
Cable Segment (Related to High/Low
Threshold Setting)
Point-to-Point
Configuration
Nodes/Repeaters
High Low
1-800 800-1,600
1-800 800-1,600
1-800 800-1,400
1-600 600-1,200
1-600 600-1,200
1-600 600-1,200
1-600 600-1,200
1-600 600-1,200
1-1,000 800-1,400
1-1,000 800-1,400
Bus
Configuration
3 to 7
High Low
1-100 N/A
1-100 N/A
1-100 N/A
1-100 N/A
1-100 N/A
1-100 N/A
1-100 N/A
1-100 N/A
1-100 N/A
1-100 N/A
