Specifications
Table 3: Specifications
Product
Topology Choices
FN Media Types
Data Transfer Rate
Number of Nodes
Allowed
Number of
IFC Panels per
Fire-Net NCM
Recommended
Ambient Operating
Conditions
Agency Listings
Termination Method
Power
Requirements
* Must be connected to an Uninterruptable Power Supply (UPS) that is UL 1481 Listed
or Recognized.
** This rating is based on full use of the power supply capacity and excludes the power
requirements for high capacity battery chargers and/or optional notification appliance
circuit power supplies, which may be required to supplement the main power supply
and/or audio amplifier power requirements.
Metasys Intelligent Fire Network
FN configurable as: Ring (recommend Style 7) or as Star,
Bus, or Hybrid (which are Style 4 configurations).
Non-shielded Wire (12 to 18 AWG, twisted pair,
3,000 ft maximum)
Fiber Optic Cable (dual-fiber, multi-mode,
62.5 x 125 micrometers,
820 nanometers wave length,
ST style connectors, 10 dB maximum
signal attenuation per segment).
Combination of Wire and Fiber Optic
NFPA Style 4 (Class B) or Style 7 (Class A). For distance
capabilities of each medium, see the Twisted Pair Copper
Wire Circuits or the Fiber Optic Cable Circuits sections of this
technical bulletin.
312.5K baud
ARCNET technology
50 maximum
10 maximum (On the Secondary Reporting Fire Network, a
maximum of four IFC panels can be connected to the
NCM-350.)
10 to 40°C (50 to 104°F)
20 to 80% RH
UL 864 UOJZ Listed
Terminating resistors on MIBs and repeaters for FN wire media
Fire OWS PC*
Fire-MON -17*
Fire-MON -21*
Fire Watchdog
Enclosure*
Fire-Net NCM*
PRN-3 Printer*
PRN-4 Printer*
INA
IFC-1010/2020 Panel
IFC Networking—Metasys Intelligent Fire Network
115 V (90-135 VAC) at 3.5 amperes
or 230 V (180-265 VAC) at
2.0 amperes
100 to 120 VAC at 2.5 amperes or
200 to 230 VAC at 1.5 amperes at
50 to 60 Hz
*2 watts, 120 VAC, 0.0166 amperes
at 60 Hz
120 to 230 VAC, 500 mA at
50-60 Hz
0.66 amperes, 120 V, 60 Hz,
0.5 amperes while printing
0.66 amperes, 120 V, 60 Hz,
0.5 amperes while printing
24 VDC with secondary battery
power source, 0.250 amperes
standby
120 VAC, 1.8 amperes at
50-60 Hz**
