Setting the
Ground Fault
Switch
Node
Addresses
Commissioning and
Troubleshooting Procedures
The switches on the MIB enable or disable ground fault detection. SW1
corresponds to Channel A and SW2 corresponds to Channel B.
All network nodes connected to either the N1 LAN or the FN must have a
node address (also referred to as a node number) to identify it on either
one or both of the networks. IFC panels, INAs, Fire-Net NCMs, and
Fire OWSs are all FN nodes. The IFC panels and INAs are only connected
to the FN, while the Fire-Net NCM and Fire OWS are connected to both
the N1 LAN and the FN.
Since they connect to two networks, certain restrictions apply to the
Fire-Net NCM and Fire OWS node addresses. The node addresses for the
Fire OWS and Fire-Net NCM must be:
• within the ranges specified in the IMPORTANT boxes below
• the same number on both the N1 LAN and the FN
IMPORTANT: The Fire-Net NCM must have an FN (Fire Network)
and Metasys Network node address between 70-79.
Fire OWS must have an FN and Metasys Network
node address between 150-159. Addresses above 249
must not be used on the FN.
Switch set On to enable
ground fault feedthrough.
Switch set Off to disable
ground fault feedthrough.
Figure 20: MIB Switches
IFC Networking—Metasys Intelligent Fire Network
switch
