Accessing
Fire OWS Data
52 IFC Networking—Metasys Intelligent Fire Network
Update Button
File View Help
Address
?
FN
Button
ADDR
Ready
Figure 22: FN Statistics Program Window
The FN Stats program allows you to view the statistics database on
one Fire OWS or Fire-Net NCM controller at a time. Both Fire OWSs and
Fire-Net NCMs write FN statistics to the FN Stats database. Once you've
viewed the database from either, you can initialize (clear/reset) the
statistics at that particular node.
After running the FN Stats program, the FN Statistics for PC or NC dialog
box automatically appears (Figure 23). To access the Fire OWS, follow the
steps below.
FN STATS FOR LOCAL PC
FN STATS FOR A FIRE NC
Figure 23: Designating Type of Data
1. Select the PC option for the Fire OWS and click OK. The PC FN
Statistics dialog box appears with the network node ID of the
Fire OWS that you are working on (Figure 24).
Note: The current version of FN Stats supports viewing the statistics
of the Fire OWS where you are running the program, but not
of other Fire OWSs on the FN.
FN Statistics Program--Untitled
?
FN STATISTICS FOR PC OR NC
NUM
window
OK
Cancel
pc_or_nc
