  • Page 1 CK722 Network Controller Network Utility Tool (NUT) March, 2016 24-10239-30 Revision D...
  • Page 3 CK722 Network Controller Network Utility Tool (NUT) March, 2016 24-10239-30 Revision D Security Solutions (805) 522-5555 www.johnsoncontrols.com...
  • Page 4 Copyright 2016 Johnson Controls, Inc. All Rights Reserved No part of this document may be reproduced without the prior permission of Johnson Controls, Inc.
  • Page 5 Johnson Controls office. For material returns contact the branch if the material was purchased through a Johnson Controls branch or through the Product Sales Operations Team, if ordered through the Advanced Order Management System (AOMS) and follow the RMA process; or contact the authorized dealer representative where the material was purchased directly.

  • Page 7: Table Of Contents

    Adding CK722 Targets........................2-7 Uploading the Disk Image Files ....................... 2-9 Downloading the CK722 Database (P2000 SCT).................. 2-12 Troubleshooting ............................. 2-13 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.
  • Page 8 Table of Contents CK722 Network Utility Tool 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.
  • Page 9 To update the firmware for a properly functioning controller, use the P2000 Host software’s firmware update feature. Refer to the P2000AE Software User Manual for details. Using the Network Utility Tool to install the CK722 OS and firmware can take 15 minutes, plus any setup and breakdown time. OTES If you remove power from the CK722 before the device has completed the ...

  • Page 10: Chapter 1: Introduction

    ERMS – A CK722 disk image is a collection of all the software files needed for the CK722 Disk Image installation of the controller’s OS and firmware.

  • Page 11: Java Technology Requirements

    Network Utility Tool screen. MPORTANT Do not run the CK722 Network Utility Tool on a P2000 server or workstation, as this may cause a network conflict with the Dynamic Host Configuration Protocol (DHCP) server.

  • Page 12: Media Access Control (Mac) Address

    Media Access Control (MAC) Address Know the Media Access Control (MAC) address of the CK722 that will receive the latest OS and firmware. Find this information in one of the following ways: The sticker on the side of the CK722’s enclosure contains the MAC address.

  • Page 13: Terminal Emulation Software (Optional)

    If a CK722 controller has an existing name that violates the standards, and you choose not to use the Update Target dialog box to rename the CK722 to a name that follows the standards, the CK722 is given the name NAE<MAC address> during the update.

  • Page 14: Cable Wiring

    CK722 Network Utility Tool Cable Wiring Ethernet Straight-through Cable The Ethernet straight-through cable provides a network connection from the CK722 Ethernet port to the computer’s network port via a hub or switch. Connector 1 Pinout Connector 2 Pinout 1 TX+...

  • Page 15: Null Modem Cable

    CK722 Network Utility Tool Introduction Null Modem Cable The null modem cable provides an RS-232 serial connection from the CK722 RS232C A port to the COM port of the computer running the terminal emulation software, such as Tera Term Pro.
  • Page 16 Introduction CK722 Network Utility Tool 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.

  • Page 17: Chapter 2: Installation

    Chapter I N S T A L L A T I O N This chapter describes how to use the Network Utility Tool to install the CK722 controller’s operating system and firmware. NSTALLATION VERVIEW The installation process consists of the following steps: Preparing the Computer (see page 2-1) ...

  • Page 18: Verifying Network Settings

    2. (Optional) Connect the RS232 Null Modem Cable to the computer’s COM 1 or COM 2 port. Connect the other end of the cable to the CK722’s RS232C A port. This connection enables you to use your computer as a CK722 terminal to monitor the software installation process.

  • Page 19: Installing The Network Utility Tool

    Installation In addition, verify that the Local Area Connection (LAN) for the Ethernet connection to the CK722 is enabled and all other network connections (including wireless connections) are disabled.  To verify the LAN Ethernet connection to the CK722 is enabled: 1.
  • Page 20 The Installation Complete screen appears when the Network Utility Tool is installed successfully in the C:\NAEUpdateTool folder on the computer. 6. Click Finish. 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.

  • Page 21: Configuring Tera Term Pro (Optional)

    COM1 or COM2 port, depending on the COM port you are using. Click OK. 6. From the menu bar, select Setup>Serial Port. 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.

  • Page 22: Installing The Ck722 Os And Firmware

    Copy the following disk image files from the P2000AE Version 4.1 Complete Installation Software DVD to C:\NAEUpdateTool\tftpfiles: NAE45_2.1.20_CK722_x.x.x.release.SH4.rgz  CK722_OS_x.x.x.x_NK.bin  CK722_OS_x.x.x.x.script  turboboot.img  24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.

  • Page 23: Adding Ck722 Targets

    OS and firmware.  To add a CK722 target: 1. On the Start menu, select Programs>Johnson Controls>Metasys> NAE-NIE Update Tool. The Network Utility Tool main screen appears showing the CK722 controllers you have already configured. Target Section 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc.
  • Page 24 CK722 Network Utility Tool CK722 controllers are displayed as NAE controllers in the Device Type column. If you have not configured any CK722 controllers, the top section of the screen (Target section) appears blank. 2. From the menu bar, select NAE/NIE>Add NAE45-x.

  • Page 25: Uploading The Disk Image Files

     To upload the disk image files: 1. On the Start menu, select Programs>Johnson Controls>Metasys> NAE-NIE Update Tool. The Network Utility Tool main screen appears showing the CK722 controllers you have already configured. 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc.
  • Page 26 To save the contents of the Network Utility Tool log to a .txt file at any time in the process, select File>Save Diagnostic Log from the menu bar. 3. Make sure the Status column entry for the CK722 is set to Enabled. If the Status entry is not Enabled, double-click on the Status column entry for the CK722 you want to update.
  • Page 27 The Network Utility Tool detects the CK722 reboot and begins the installation. The log portion of the screen shows the progress of the installation. The CK722 update takes place in four stages, with a total update time of approximately 15 minutes: The CK722_OS_x.x.x.x_NK.bin file downloads in approximately ...

  • Page 28: Downloading The Ck722 Database (P2000 Sct)

    CK722 to the Ethernet network shared with the P2000 server. If you have other CK722 controllers to update, connect the computer and hub/switch to a new CK722 and repeat Step 1 through Step 6 of this section. 7. Close the Network Utility Tool session.

  • Page 29: Troubleshooting

    This application usually comes on the installation disk from the Internet Service Provider (ISP). Please contact your ISP if you need help with this application. 24-10239-30 Rev. D 2-13 This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.
  • Page 30 Alternatively, back up and remove the archive file (archive.moi). Reload the archive after the update is complete. 2-14 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.
  • Page 31 Ignore this message and click OK. the log screen: Bootstrap Loader file must belong to a release later than x.x.x. 24-10239-30 Rev. D 2-15 This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.
  • Page 32 Installation CK722 Network Utility Tool 2-16 24-10239-30 Rev. D This document contains confidential and proprietary information of Johnson Controls, Inc. © 2016 Johnson Controls, Inc.
