Johnson Controls Metasys Intelligent Fire Network Technical Manual page 66

PRESS 1=PSYS, 2=FSYS, 3=PPRG, 4=FPRG, 5=REMV, 6=PSWD, 7=MSG, 8=HIS:3
PRESS 1=TYPID, 2=CBE, 3=LBL, 4=OPTNS, 5=AMAP, 6=CCBE
ENTER LXX (D/M) YY, ZXXX OR AXXPYY FOR PT. INSTALL (BCKSPC TO ABORT)
ENTER COOPERATIVE CONTROL-BY-EVENT OR
(N8Z1 N8Z2 N8Z3 N8Z4 AND [N9Z1 N9Z2 N9Z3 N9Z4] AND [N10Z1 N10Z2 N10Z3 N10Z4])
66 IFC Networking—Metasys Intelligent Fire Network
3=PPRG
Select Partial Point
Programming Submenu
Option 1-6
Figure 29: Partial Point Programming Flowchart
A partial point-programming example to change a CCBE is as follows:
1=TYPID
(change device, zone, or annunciator
point software type ID)
2=CBE
( hange CBE list or equation which c
controls interaction between devices
and software zones)
3=LBL
( hange custom label associated with c
each device and software zone)
4=Options
(enable/disable for each device signal
silence, walk test, alarm verification,
sensitivity, or tracking)
5=AMAP
(individually maps devices or software
zones to annunciator points for remote
annunciation)
6=CCBE
( hange CCBE equation for reverse c
activated zones)
prgfc
:6
:Z220
:
