Extron electronics Control Panel CTL208CM Specifications

Specifications — CTL208CM Control Panel
Serial control
Serial control port ........................ 1 RS-232, RS-422, or RS-485; 3.5 mm, 5 pole captive screw connector
Baud rate and protocol ............... 1200, 2400, 4800, 9600 (default), 19200, or 38400 baud; 8 data bits; 1 stop bit; no
Pin configurations
RS-232 ................................ 3 = TX, 5 = RX, 1= GND
RS-422/RS-485 ................. 3 = TX+, 2 = TX-, 5 = RX+, 4 = RX-, 1 = GND
Program control ........................... Inline Control Software – ICS100
General
External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable; to 12 VDC, 1.0 A
Power input requirements ......... 12 VDC, 0.5 A
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Rack mount ................................... No, but wall- or furniture-mountable with optional CPM connector plates
Enclosure type .............................. Metal
Enclosure dimensions
Faceplate ........................... 2.8" H x 2.2" W x 0.1" D
Device ................................ 2.8" H x 1.9" W x 1.4" D
Product weight ............................. 0.25 lbs (0.1 kg)
Shipping weight ........................... 2 lbs (1 kg)
Listings .......................................... ETL (UL1950), UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
1-2
CTL208CM • Specifications
parity (default), even parity, or odd parity; half (default)/full duplex
ASCII character command set
regulated
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(7.1 cm H x 5.6 cm W x 0.3 cm D)
(7.1 cm H x 4.8 cm W x 3.6 cm D)
(Depth excludes buttons.)
(7.52-100406-D3)
