Teldat S.A.
A.4.7 Power supply
NOMINAL
ABSOLUTE MAXIMUM
FREQUENCY
MAXIMUM POWER
CONNECTOR
A.4.8 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.4.9 Environmental specifications
TEMPERATURE
RELATIVE HUMIDITY
Regesta PLC
100-240 V AC.
85-264 V AC.
50-60 Hz
9 W.
Terminal Block 2 Poles 5mm pitch. Same as the PLC PRIME interface.
Plastic ruggedized casing with optional DIN rail mount.
140 x 80 x 190 mm.
750 gr.
OPERATING NORMALLY: -25 ºC to +60 ºC
STORED: -25º to +70 ºC
On: 5 % to 93 %
Technical Information
31
