The Regesta PLC incorporates independent modules for the Wireless WAN interface. You can pick modules from
different manufacturers or choose several modules from the same provider, depending on the technology used. Gen-
erally, the firmware is independent from the device's software. There is an UPGRADE file for each Wireless WAN
module. Please ask you distributor for the correct UPGRADE file (according to the module in your device). The
manual describing the Cellular interface (Dm781-I) explains how to upgrade the module.
The Regesta PLC also incorporates a PLC module, which need its own firmware. This PLC module can operate in
several modes. To change operating mode, you usually need to change the PLC firmware. This firmware is inde-
pendent of all other software in the device. Please ask your distributor for the correct PLC UPGRADE file. The manu-
al describing the PLC Gateway (Dm 823-I) explains how to upgrade the module.
A.2.1 Connecting to the router
There are two ways of accessing the device CLI:
A.2.1.1 Connecting through the local console (CONF connector)
The Regesta PLC has a RJ.45 female connector on the front panel known as CONF., which provides access to the
device local console. To configure this, connect the CONF. port to an asynchronous terminal (or to a PC with termin-
al emulation).
To connect to the configuration port, use the RJ45 cable (provided with the router) and the female RJ45-female DB9
adapter (also provided with the router). If the terminal has DB25 connectors, an additional adapter will be needed.
Connecting for configuration
Fig. 23:
A.2.1.2 Connecting through an IP terminal (LAN connector)
The Regesta PLC includes a default configuration that activates if you haven't preconfigured anything.
The router's default configuration establishes the following IP address and access mask:
Regesta PLC
• Through the CONF connector.
• Through the Telnet protocol.
• Speed: 9600 bps.
• Eight data bits.
• One stop bit.
• No parity bit.
• No type of flow control.
• IP address: 192.168.1.1
• IP mask: 255.255.255.0
