3 Components and Power Supply
Multi standard seri-
S2
al interface 2
Please note that some LEDs may behave differently depending on how the device is configured.
3.1.2 Connector panel
The connector panel is covered by a protective casing.To access the connection panel you need to remove the pro-
tection. For further information on how to remove/install the protective casing, please, see
connector cover
The following figure shows the connector panel. This panel includes all Regesta PLC router connectors.
Connector Panel
Fig. 3:
The connector panel components are as follows:
Table 2: Connector panel components
Item
A
B
C
D
E
F
8
Off
Green
on page 10.
Description
RST. Reset button. For further information on how the reset button works, please see
button on page 15.
CONF. RJ-45 connector providing access to the device's local console for configuration and
monitoring purposes. (This connector can also be used as an RS-232 asynchronous DCE
serial port.)
Fast Ethernet Port 1.
Fast Ethernet Port 2 (Optional). This port can support up to 10 KV of voltage isolation, de-
pending on model.
POWER/PLC. Power connection and PLC signal injection. For further information on the
power connection, please see
RS485,RS232. For more information on the connector for serial ports, 2-4 wire RS-
485/RS-422 and DCE RS-232, see
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Serial port 2 is disabled or not initialized.
Port is in active state, shows interface activity:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Power source on page 14.
Connecting the serial ports
Removing/Installing the
RST
on page 18.
