Cellular interface
S
Cellular interface
C
Cellular interface
L
corresponding to
the active SIM.
Ethernet (LAN) in-
E1
terface 1
Multi standard seri-
S1
al interface 1
Ethernet (LAN) in-
E2
terface 2
Regesta PLC
PRIME PLC is running, SNs are detected and DC connection
Green
is working. PRIME traffic can be sent through PLC interface.
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
For Service Node operation mode:
Off
PRIME PLC interface is disabled, unavailable or not installed.
PRIME PLC interface is running, but SN is not connected to
Red
BN.
Green
PRIME PLC is running and connection to BN is established.
PRIME traffic from UDP/IP can be sent to PLC interface.
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Green SIM1 operating SIM. This is processing traffic through the car-
rier for the SIM installed in this tray.
Amber
SIM2 operating SIM. This is processing traffic through the car-
rier for the SIM installed in this tray.
Red Cellular interface is unavailable, not installed or not registered.
The device has registered in the network and is establishing
Amber
the PDP connection.
The device is registered, PDP connection is established and
Green
IP traffic can be sent through the CELLULAR interface.
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off Cellular interface is not active.
Red Coverage level below -100dBm.
Amber Coverage level between -90dBm and -100dBm.
Green Coverage level above -90dBm.
Off Ethernet port 1 is disabled or connection is not established.
Ethernet connection (link) established:
Green
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off Serial port 1 is disabled or not initialized.
Port is in active state, shows interface activity:
Green
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off Ethernet port 2 is disabled or connection is not established.
Ethernet connection (link) established:
Green
