Technical Information
A.4.2 LAN interfaces
PROTOCOLS
PORTS
SPEED
CONNECTOR
ISOLATION
A.4.3 Wireless WAN interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
A.4.4 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.4.5 RS-232 Serial interface
STANDARDS
SPEED
CONNECTOR
A.4.6 RS-485 Serial interface
STANDARDS
SPEED
CONNECTOR
30
Ethernet (802.3).
2 ports (1 port is optional) with MDI/MDX auto detection with 10KV isolation option
(for optional port only).
10/100 mbps (BaseT).
RJ45 female.
Standard for E1 interface (1.5 KV), high optional isolation for E2 (up to 10 KV).
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... depending on the device's wire-
less WAN version.
Depends on the device's wireless WAN version. Please see the manual on the rel-
evant module.
2 RF SMA female. (the router may only include 1 connector: this depends on the
WWAN module technology).
Depends on the type of wireless WAN. Please see the antenna catalog for Cellu-
lar interfaces.
V.24 9.600-8-N-1-without flow control.
RJ-45 female on the device's connector panel.
RS-232. Asynchronous serial port without control signals.
From 300 to 115200 bps.
Terminal block 4 pin pluggable, on the device's connector panel (optional).
2-4 wires RS-485/RS-422 configurable through software. Bus termination config-
urable through software.
From 300 to 115200 bps.
Terminal block 3 pin pluggable, on the device's connector panel (optional).
