REMKO Smart Control Touch Operating Manual page 75
For sqw heat pumps
Hide thumbs
Also See for Smart Control Touch:
- Operating and installation instructions (24 pages) ,
- Operating manual (108 pages)
Table of Contents
Advertisement
Connection of the remote control to the I/O module with a LAN cable
WLAN
Fig. 18: Connection to the I/O module
A: Remote control
B: I/O module
1: Ethernet interface / patch cable connection (LAN
cable)
Observe the separate controller instructions for commissioning and programming the REMKO Smart-
Control Touch controller.
A
1
2
2: Power supply: +12V, terminal B1/A1
B
75
