Operating manual
REMKO Smart-Control Touch
For the WSP heat pump range
From software version 4.28
Specialist and user manual
0182-2022-10 Edition 4, en_GB
Read the instructions prior to performing any task!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Control Touch and is the answer not in the manual?

Questions and answers

Related Manuals for REMKO Smart Control Touch

Summary of Contents for REMKO Smart Control Touch

  • Page 1 Operating manual REMKO Smart-Control Touch For the WSP heat pump range From software version 4.28 Specialist and user manual 0182-2022-10 Edition 4, en_GB Read the instructions prior to performing any task!
  • Page 2 Read these operating instructions carefully before commis- sioning / using this device! These instructions are an integral part of the system and must always be kept near or on the device. Subject to modifications; No liability accepted for errors or mis- prints! Translation of the original operating manual...

  • Page 3: Table Of Contents

    Table of contents Safety and usage instructions......................4 1.1 General safety notes........................4 1.2 Identification of notes........................4 1.3 Personnel qualifications........................4 1.4 Dangers of failure to observe the safety notes................4 1.5 Safety-conscious working....................... 4 1.6 Safety notes for the operator......................5 1.7 Safety notes for installation, maintenance and inspection..............

  • Page 4: Safety And Usage Instructions

    REMKO Smart-Control Touch Safety and usage instructions CAUTION! This combination of symbol and signal word 1.1 General safety notes warns of a potentially hazardous situation, which if not avoided may cause injury or mate- Carefully read the operating manual before com- rial and environmental damage.

  • Page 5: Safety Notes For The Operator

    The setup, connection and operation of the plete and return the "certificate of warranty" to units and its components must be undertaken REMKO GmbH & Co. KG at the time when the in accordance with the usage and operating units are purchased and commissioned.

  • Page 6: Transport And Packaging

    REMKO Smart-Control Touch 1.11 Transport and packaging The devices are supplied in a sturdy shipping con- tainer or inside the heat pump casing. Please check the equipment immediately upon delivery and note any damage or missing parts on the delivery and inform the shipper and your contrac- tual partner.

  • Page 7: Technical Data

    Technical data Series Smart Control Touch Power supply +12 V DC Enclosure class Power consumption < 100 Max. cable length Recommended cable 2 x 0,5 Dimensions Height Width Depth Environment Ambient temperature °C 0-70 Air humidity % rH 0-95 (relative) non-condensing...

  • Page 8: Operation - General Notes

    Selecting user/expert mode General notes You can access the expert level by touching the REMKO logo in the upper right corner of the dis- Overview of the controls play. After entering the password (0321) using the +/- combination and then touching the "Next" and "OK"...
  • Page 9 The tiles (widgets) in the basic display can be Menu Home Parameters changed individually for each operator. To change a widget, you must adjust the displays in the "Set- tings" level. The adjustments can be made in the level described below. Settings Basic settings Display...

  • Page 10: Operation - User Level

    REMKO Smart-Control Touch Operation - User level 4.1 Menu structure Overview Information Settings Messages Room climate Basic Basic settings Fault messages mode information Warning notices Colder/ Solar Solar warmer Storage tank Hot water Hot water set temp. Weather Stored Heating/...
  • Page 11 In the settings menu item it is possible to adjust parameters for the enabled components. Here, you have the option of adjusting e.g. heating curves in accordance with the requirements the REMKO heat pump user. Relevant points that affect the safety of the complete system are only to be changed by a specialist.
  • Page 12 REMKO Smart-Control Touch "Information" menu item - User This menu contains information about the current operating status of the system. Level 2 menu item Level 3 menu item Level 4 menu item Detected unit Current operating mode Previous operating mode...
  • Page 13 "Information" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item USB interface IP address Subnet Network (USB) Basic information Gateway (continued) MAC address WLAN status Licence information Level 2 menu item Level 3 menu item Pump A01 Pump control signal A40 Control signal A01...
  • Page 14 REMKO Smart-Control Touch "Information" menu item (continued) - User Level 2 menu item Level 3 menu item Operating mode Set temperature Actual temperature Room set temperature Unmixed Room actual temperature Room humidity Dew point Mixed outside temperature Operating mode Set temperature...
  • Page 15 "Information" menu item (continued) - User Level 2 menu item Level 3 menu item Operating mode Set temperature Actual temperature Room target temperature 4th mixed cycle *) Room actual temperature Room humidity Dew point Mixed outside temperature Demand Heating water temp. (setpoint) Heating water temp.
  • Page 16 REMKO Smart-Control Touch "Information" menu item (continued) - User Level 2 menu item Level 3 menu item Heat pump status Remaining idle time Compressor status Fault status Heat pump Target temperature Enable signal Disable compressor Disable signal S16, energy supplier cut-off...
  • Page 17 "Information" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item Current output Solar Solar yield Thermal power, heat pump Thermal energy, heat pump Electrical power, heat pump Heat pump Electrical energy, heat pump Output, environment Environmental energy Current household output...
  • Page 18 REMKO Smart-Control Touch "Settings" menu item - User In this menu you can configure the settings. For example, you can adjust hot water and heating tempera- tures or change time settings. Level 2 menu item Level 3 menu item Level 4 menu item...
  • Page 19 User profile Away mode Mode Party mode Heating/cooling Difference from cooling limit Difference from heating limit Standard outside temperature (heating) Building adaptation Standard outside temperature (cooling) Operating mode Parameters for REMKO MWL Source storage tank Fixed value Parameters for REMKO MWL...
  • Page 20 REMKO Smart-Control Touch "Settings" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A...
  • Page 21 "Settings" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A 1st mixed Time program B cycle Time program C...
  • Page 22 REMKO Smart-Control Touch "Settings" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A...
  • Page 23 "Settings" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A 3rd mixed Time program B Cycle (I/O 2) *) Time program C...
  • Page 24 REMKO Smart-Control Touch "Settings" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A...
  • Page 25 "Settings" menu item (continued) - User Level 2 menu item Level 3 menu item Level 4 menu item Number of power tariffs Heat pump Graduated tariff Time field Tariff 1-9 Power tariff 1-9 Power tariff 1 PV current Feed-in tariff Consumption Personal use tariff Mode...

  • Page 26: Setting The Heating/Cooling Operating Mode

    REMKO Smart-Control Touch 4.2 Setting the heating/cooling 3: Return flow heating curve 4: Outside temperature in °C operating mode Heating curve heating circuit mode For optimal configuration of the heating curve The heating curve can be adjusted in three points,...
  • Page 27 Settings ¯ The mixed heating cycles each require a supply and return probe! These probes are included in the Heating/cooling scope of supply of the mixed REMKO heating cir- ¯ cuit groups. Building adaptation ¯ Activation of the cooling function via the...
  • Page 28 REMKO Smart-Control Touch Cooling curve cooling circuit mode For optimal configuration of the cooling curve parameters, the cooling load calculation and/or The cooling curve can be set at three points, energy consumption must be taken into account. depending on the structural and location-related...
  • Page 29 With this, the cooling circuit regulates to an aver- aged temperature. The value is calculated from the A cooling function via the cooling curve setting inlet temperature plus the return temperature is only enabled by REMKO if the corresponding divided by two. humidity probe is installed! User level Expert level ¯...
  • Page 30 CAUTION During cooling mode via the underfloor/panel heating system, make sure that the dew point is not undershot. REMKO recommends installing dew point probes in conjunction with one (max. five probes for dew point monitoring) or more dew point monitors.

  • Page 31: Changeover Summer/Winter Mode

    The adjustment of this summer/winter changeover October to the start of May of the following year), is described in the following steps. the REMKO heat pump must provide constant heat for the heating operation. Heating limit The heat pump, circulation pumps and heating sur-...
  • Page 32 Only the hot water supply is still active. The building time constant is preset by REMKO in Overview (user) the factory at 10 hours. Setting the building time constant should prevent the heat pump from ¯...

  • Page 33: Wlan Function

    WLAN network of the in-house router, access to encryption/security standard the heat pump parameters is not possible. Installation in house The central controller for the REMKO heat pump via a smart phone or other mobile devices can be installed virtually anywhere in the building. WLAN WLAN Fig.
  • Page 34 Note that the REMKO Smart-Control Touch only This is only possible at the expert level. To do so, supports the WPA 2 encryption/security standard. touch the REMKO logo in the upper right corner of For this purpose you must know the name of your the display.
  • Page 35 You now have the option of ¯ controlling the relevant operating parameters for the user and expert level of your REMKO heat Network (USB) pump via a PC, laptop or smartphone. connected (IP address) This function is available to you constantly whilst connected to the WLAN network of your router.

  • Page 36: Emergency-Heat Operation

    "Heat pump" must be changed from "acti- Then confirm the change with "OK". vated" to "deactivated". This is only possible at the expert level. To do so, touch the REMKO logo in the upper right corner of the display. System configuration After activating the expert level by touching the ¯...

  • Page 37: Operation - Expert Level

    Information You can access the expert level by touching the You can obtain basic information about the com- REMKO logo in the upper right corner of the dis- plete system here. play. Here, you will also find corresponding information...
  • Page 38 REMKO Smart-Control Touch Overview Information Settings Messages Room climate Basic Basic Fault messages settings mode information Warning notices Colder/ Solar Solar warmer Storage tank Hot water Hot water set temp. Weather *) Heating/ Stored information Cooling energy Unmixed Stored cycle...
  • Page 39 "Information" menu item - Expert This menu contains information about the current operating status of the system. Depending on the heat pump installed and the design, individual parameters may vary from version to ver- sion. Level 2 menu item Level 3 menu item Level 4 menu item Detected unit Control algorithm...
  • Page 40 REMKO Smart-Control Touch "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Hardware control panel Hardware Software control panel Software Software (I/O 2) *) Linux Kernel Control Panel Linux Kernel Version number µPC edition *)
  • Page 41 "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Pump control signal A01 Pump control signal A40 Collector temperature S01 Storage tank temperature, bottom S02 Storage tank charging status Solar Current output Solar yield Inlet temperature S03 Return temperature S04 Medium flow rate S23 Stored energy...
  • Page 42 REMKO Smart-Control Touch "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Operating mode Set temperature Actual temperature Room set temperature Room actual temperature Room humidity Dew point Unmixed cycle Mixed outside temperature Pump speed rel. A42...
  • Page 43 "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Operating mode Set temperature Actual temperature Inlet temperature S06 Return temperature S14 Room set temperature Room actual temperature Room humidity 2nd mixed Dew point cycle Mixed outside temperature Pump speed rel.
  • Page 44 REMKO Smart-Control Touch "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Operating mode Set temperature Actual temperature Inlet temperature S06.2 Return temperature S14.2 Room set temperature Room actual temperature Room humidity 4th mixed Dew point...
  • Page 45 "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Demand Hot water temperature (setpoint) Hot water temperature (actual value) Therm.output Inlet temperature S13 Inlet temperature S13.2 Inlet temperature mixed Return temperature S15 Return temperature S15.2 Return temperature, mixed Set medium flow rate Actual medium flow rate S24...
  • Page 46 REMKO Smart-Control Touch "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Heat pump status Remaining idle time Compressor status Fault status Target temperature Enable signal Disable compressor Disable signal S16, energy supplier cut-off Max.inlet temperature...
  • Page 47 "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Heat pump status Remaining idle time Compressor status Fault status Target temperature Enable signal Disable compressor Disable signal S16, energy supplier cut-off Max.inlet temperature Source pump Source pump speed Water inlet temperature Water outlet temperature...
  • Page 48 REMKO Smart-Control Touch "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Heat generator status Heat generator stage Potential-free output A32 Potential-free output A32.2 Auxiliary heat generator Potential-free output A 33 Potential-free output A33.2...
  • Page 49 "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Current household output Household energy (day) Household energy (week) Household Household energy (month) Household energy (year) Household energy Photovoltaic output PV yield (day) PV yield (week) PV yield (month) PV yield (year)
  • Page 50 REMKO Smart-Control Touch "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item Collector temp. S01 Lower storage tank temp. S02 Inlet temperature S03 Return temp. S04 Circulation actual temp. S05 Circulation request S05 Inlet temperature S06 Inlet temperature S06.2 *)
  • Page 51 "Information" menu item (continued) - Expert Level 2 menu item Level 3 menu item IP of the KNX interface MAC for the KNX interface Address of the interface Physical address KNXnet/IP *) KNX connection status Programming mode Programming mode interface Application version *) Activation only with supplementary software...
  • Page 52 REMKO Smart-Control Touch "Settings" menu item - Expert In this menu you can configure the settings. For example, you can adjust hot water and heating tempera- tures or change time settings. Depending on the heat pump installed and the design, individual parameters may vary from version to ver- sion.
  • Page 53 "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Level 5 menu item DHCP via input Use DHCP Network Local IP address Subnet mask Gateway address USB Ethernet Authentication Basic settings Interfaces (continued) SSID...
  • Page 54 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Level 5 menu item Smart Com Protocol Interface search IP of the KNX interface Re-couple interface Physical address KNXnet/IP...
  • Page 55 "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Level 5 menu item Buffer tank sources Unmixed circuit 1st mixed cycle 2nd mixed cycle 3rd mixed cycle *) 4th mixed cycle *) System separation FBH Setpoint increase Separate cooling buffer *)
  • Page 56 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Max. temperature Max. temperature hysteresis Min. temperature Collector Min. temperature hysteresis Switch-on difference Switch-off difference Solar set temperature Solar set temperature hysteresis Storage tank Collector cooling function ON temp.
  • Page 57 "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Compressor restriction Storage tank set temperature Mode Time program A Time program B Domestic hot-water heating Time program C Tolerance during ECO operation Speed in hot water A43 Pump parallel operation Switch-off delay Hot water valve...
  • Page 58 REMKO Smart-Control Touch Factory-set circulation switching times Designation Value range Factory setting Customer system Time program Mon-Sun Mon-Sun 00:00-24:00 Hygiene function Designation Value range Factory setting Customer system Set temperature "60 °C - 75 °C" 60 °C Day of activation...
  • Page 59 "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Heat requirement calculation Pump speed A43 Building time constant Standard heating load Standard outside temp. (Heating) Building adaptation Standard outside temp. (Cooling) Max.
  • Page 60 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Excessive temperature in the heating buffer Stored energy Excessive temperature in the hot water buffer Internal pump A43 Operating mode Fixed value Buffer tank sources...
  • Page 61 "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Status Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A Time program B Time program C Time program function Room temperature reduction Room temperature increase...
  • Page 62 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Status Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A Time program B...
  • Page 63 "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Status Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A Time program B Time program C Time program function Room temperature reduction Room temperature increase...
  • Page 64 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Status Operating mode Heating cycle mode Fixed value Heating curve adjustment Cooling cycle mode Fixed value Cooling curve adjustment Time program A Time program B...
  • Page 65 Unmixed & mixed circuit switching times Designation Factory setting Customer system Time program A Mo-Su 00:00-24:00 Time program B Mo-Fr 05:00-23:00 Sa-Su 06:00-23:00 Time program C Mo-Fr 05:00-23:00 Sa-Su 06:00-23:00 Level 2 menu item Level 3 menu item Limitation Passive cooling Min.
  • Page 66 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Activating DT regulation Temperature difference setpoint Min. pump speed A43 Max. pump speed A43 Cooling pump actuation Brine outlet setpoint...
  • Page 67 "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item PV personal use variant Power tariff 1 Feed-in tariff Personal use tariff Factor for PV power surplus Damping electrical power Hot water setpoint PV current usage Setpoint heating Setpoint cooling...
  • Page 68 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Level 2 menu item Level 3 menu item Level 4 menu item Operating mode 3-speed heating element Response to disable signal S16 Auxiliary heat generator Min. pump speed A 43 (%) Max.
  • Page 69 "Settings" menu item (continued) - Expert Manual mode - relay test With this menu item, you can control the individual actuators (pumps, mixing valves, etc.) manually or specify values of probes for checking. Parameter Selection parameter Manual mode Permanent / Deactivated / 15 minutes Solar cycle pump Auto / On / Off Speed...
  • Page 70 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Manual mode - relay test (continued) With this menu item, you can control the individual actuators (pumps, mixing valves, etc.) manually or specify values of probes for checking. Parameter Selection parameter...
  • Page 71 "Settings" menu item (continued) - Expert Manual mode - probes Parameter Selection parameter Manual mode Permanent / Deactivated / 15 minutes Probe value Brine inlet temp. Default value Temperature -60°C - 250°C Probe value Brine inlet temp. S07.2 Default value Temperature S07.2 -60°C - 250°C...
  • Page 72 REMKO Smart-Control Touch "Settings" menu item (continued) - Expert Manual mode - probes (continued) Parameter Selection parameter Manual mode Permanent / Deactivated / 15 minutes Probe value 2nd mixed cycle return temperature Default value Temperature -60°C - 250°C Probe value 4th mixed cycle return temperature S14.2...
  • Page 73 "Settings" menu item (continued) - Expert Commissioning Information on the "Commissioning" menu item is described in the separate "Commissioning wizard" chapter on the next pages. "Settings" menu item (continued) - Expert Chimney sweep Level 2 menu item Level 3 menu item Mode Normal operation/test mode Hot water valve...

  • Page 74: Commissioning Wizard

    REMKO Smart-Control Touch 5.2 Commissioning wizard When starting the controller for the first time the commissioning assistant is started in order to implement the basic programming of the existing system. After commissioning has been fully completed, the default set of parameters is enabled.
  • Page 75 Setting the language All menu entries, commands and parameters are displayed in plain language in the language selected. Menu item Parameter Factory setting Deutsch English Francais Italiano Language setting Espanol Deutsch Portugues Nederlands Polski Čeština Setting the time zone for the winter time Selecting the time zone for the winter time allows the switch to daylight savings time to occur automatically.
  • Page 76 REMKO Smart-Control Touch Setting the time From here, you can set the current time. The controller has automatic summertime switching, which can also be activated from the menu "Language/Time” (+1 CET). When setting the time, first the hours are selected, and then the minutes.
  • Page 77 Operating mode Two operating modes are available: Bivalent alternative Monoenergetic Menu item Parameter Factory setting Monoenergetic Operating mode selection Monoenergetic Bivalent alternative Selection of the auxiliary heat generator: - Bivalent alternative (heat pump or oil/gas-fired boiler or wall heating) - Monoenergetic (heat pump and/or Smart Serv electric heating element) according to usable limits The operating mode of the internal pump in the indoor unit must be defined here in the level “Expert "...
  • Page 78 Optionally, the "Source buffer tank" function can be activated. Activation must take place when the heat pump is used as a heat source of the buffer tank for supplying the REMKO MWL heat pumps. If the heat pump is not required as a heat source for the MWL heat pumps, activation of this function is not necessary...
  • Page 79 Circulation type (dependent on which probes are used) Impulse circulation: (Only in conjunction with the REMKO impulse generator) If briefly dispensing water triggers an impulse on the flow-operated safety device, this is registered by the controller and the circulation pump is started up. This means that the circulation is also active when it is required.
  • Page 80 The descriptions of the 1st and 2nd mixed heating cycle are identical to the unmixed heating cycle. The mixed heating cycles each require a supply and return probe! These probes are included in the scope of supply of the mixed REMKO heating circuit groups.
  • Page 81 Standard outside temperature (heating) The standard outside temperature must be set to the appropriate value for the region. After setting the cor- rect temperature, this is stored for all activated heating circuits that are to be controlled in accordance with a heating curve.
  • Page 82 REMKO Smart-Control Touch Setting the building time constant The building time constant specifies the ability of the building to retain heat. The building time constant is dependent upon the type of building (see table). The value is also dependent on individual temperature per- ception, and so the information in the table should only be treated as a guide.
  • Page 83 Solar plant Deactivation if no solar plant is available. It can be activated again at a later date. Activation if a solar plant is available. Menu item Parameter Factory setting Deactivated Solar plant Deactivated Activated Selecting the pump system Select the pump system for the speed controller. The speed control system is available for a solar cycle with asynchronous pump (controlled by an A01 with "wave packets"), as well as for one or two solar cycles with high-efficiency pump (controlled by an A01 with "PWM").
  • Page 84 Menu item Parameter Factory setting Solar set temperature 5 °C - 95 °C 85 °C REMKO recommends installing a domestic hot water mixer with solar hot water preparation. WARNING! Implement measures on site to ensure sufficient scalding protection!
  • Page 85 Heat carrier medium Selection of the filled solar liquid for calculation of the amount of solar heat. Menu item Parameter Factory setting Water DOWCAL 10 DOWCAL 20 TYFCOR TYFOCOR-L TYFOCOR-LS ANTIFROGEN-N Heat carrier medium ANTIFROGEN-SOL TYFOCOR-L Temper-10 Temper-15 Temper-20 Temper-30 Temper-40 Temper-55 GLYTHERMIN P44...

  • Page 86: Hygiene Function/Legionella Circuit

    Hot water tank capacity. ¯ The precondition for the dynamic hygiene function is that a REMKO flow sensor (e.g. EDP no. Hygiene function 254070) has been installed. The dynamic hygiene function can be individually adjusted to the user ¯...
  • Page 87 Overview of all of the parameters relevant for the static or dynamic hygiene function. Static Dynamic Description Set temperature Setting the target temperature Day of activation Setting the first weekday Time of activation Setting the starting time The hygiene function is only active if the tank contents of the hot water storage tank have not been changed Inspection time for 72 hours.

  • Page 88: Activate Heating And Cooling Cycle, Examples

    ¯ in the chapter "Setting the heating/cooling oper- ating mode". Heating Cooling ¯ Heating & cooling System configuration ¯ Deactivated Activated The REMKO Smart-Control Touch controller can control max. one unmixed and four mixed heating circuits!

  • Page 89: Template Hydraulics With Installation Parameters

    We recommend adapting plant-specific parameters, such a heating limits and bivalence point, to the design data! You can find further hydraulics examples at www.remko.de Hydraulic circuit diagram Functions: Heating and hot water incl. Smart-Serv emergency heating coil Fig. 12: Example hydraulic diagram...
  • Page 90 REMKO Smart-Control Touch Basic settings for the hydraulic diagram Menu item Parameter Factory setting Country Deutschland - Slovensko Germany Load setting Accept the parameters Saving process Language Deutsch - Polski Deutsch Time zone Var. time zones possible Winter + 1(CET)
  • Page 91 Menu item Parameter Factory setting Fixed value "10 °C - 60 °C" Deactivated Cooling cycle mode Cooling curve/Fixed value Deactivated Fixed value "8 °C - 35 °C" Deactivated Base point/standard inlet temperature/ Cooling curve adjustment Deactivated standard outside temperature 2nd mixed heating cycle Activated / Deactivated Deactivated Operating mode...

  • Page 92: Error Messages On The Smart Control

    REMKO Smart-Control Touch Error messages on the Smart Control Operating messages, warnings and error display on the Smart-Control Operating messages Description Desig. Details Storage tank 1: Max. The temperature on one of the probes in storage tank 1 is ID6000...
  • Page 93 Description Desig. Details Heat pump bivalence temperature - the heat pump is disabled Heat pump bivalence ID6111 because the temperature has dropped below the bivalence temperature temperature ID6113 Solar heating Solar heating - heat generators are disabled Temperature dropped ID6114 Compressor is disabled for cooling function below dew point Low pressure differ-...
  • Page 94 REMKO Smart-Control Touch Description Desig. Details Suction gas temperature probe error - please check the suc- Suction gas tempera- µPC2 ID7015 tion gas temperature probe on the inverter board and its con- ture probe error nection High pressure probe High pressure probe error - please check the high pressure µPC2...
  • Page 95 Description Desig. Details Suction gas tempera- Short circuit or open contact – probe for suction gas tempera- ID7043 ture probe fault ture, outdoor unit Register temperature Short circuit or open contact – probe register temperature, out- ID7044 probe fault door unit High-pressure probe Check the high pressure sensor of the outdoor unit and its ID7045...
  • Page 96 REMKO Smart-Control Touch Description Desig. Details ID7070 High pressure switch HP 1 The high pressure switch was triggered ID7071 Inverter interlocked HP 1 Inverter interlocked ID7072 Inverter malfunction HP 1 Inverter malfunction ID7073 DLT probe fault HP 1 Temperature probe DLT was not detected...
  • Page 97 Description Desig. Details Communication mal- ID7099 Communication malfunction - I/O module function Temperatures in the cooling cycle implausible, check the cor- ID7100 Signal line reversed rect connection of the signal lines of outdoor unit A Short circuit - cooling ID7101 Short circuit - cooling buffer tank probe buffer tank probe Open contact - cooling...
  • Page 98 REMKO Smart-Control Touch Description Desig. Details ID7120 Open contact - suction Open contact - suction gas temp. probe gas temp. probe ID7121 Short circuit - heat gas Short circuit - heat gas temp. probe temp. probe ID7122 Open contact - heat Open contact - heat gas temp.
  • Page 99 Description Desig. Details Short circuit - ID7207 Short circuit - external probe external probe Open contact - ID7208 Open contact - refrigerant probe refrigerant probe Short circuit - refrig- ID7209 Short circuit - refrigerant probe erant probe Open contact - circula- ID7210 Open contact - drinking water circulation temperature probe tion temp.
  • Page 100 REMKO Smart-Control Touch Description Desig. Details Open contact - mix. ID7238 heating cycle return Open contact - mixed heating cycle return temperature probe temp. probe Short circuit - mix. ID7239 heating cycle return Short circuit - mixed heating cycle return temperature probe temp.
  • Page 101 Description Desig. Details ID7261 Fault with probe B1 Please check probe and the connection to the inverter board Outside temperature Outside temperature probe error - please check the outside µPC ID7262 probe error temperature sensor on the inverter board and its connection Error brine outlet temp.
  • Page 102 REMKO Smart-Control Touch Description Desig. Details Low evaporation tem- The compressor is disabled due to the evaporation tempera- µPC ID7287 perature ture being too low High evaporation tem- The compressor is disabled due to the evaporation tempera- µPC ID7288 perature...
  • Page 103 Description Desig. Details Open contact - refrig- ID7306 S07.2 Open contact - refrigerant probe (I/O 2) erant probe (I/O 2) Short circuit - refrig- ID7307 S07.2 Short circuit - refrigerant probe (I/O 2) erant probe (I/O 2) Overcurrent at the inverter module IPM (IGBT transistor ID7308 WKF fault code E464 module).
  • Page 104 REMKO Smart-Control Touch Description Desig. Details Negative temp. differ- The temperature difference when the heat generator is active ID7333 ential is implausible Communication between operating unit SMT 1 and power unit ID7334 Comm. signal SMT 1 I/O was interrupted. Warnings Description Desig.
  • Page 105 Description Desig. Details Upper application area The guaranteed application area of the external unit in cooling ID8142 (cooling) mode is currently exceeded ID8144 Target flow rate (I/O 2) The flow rate has dropped below the set medium flow rate ID8150 Max. defrost duration The maximum duration for the defrost has been exceeded ID8151 Max.

  • Page 106: Index

    REMKO Smart-Control Touch Index Storage tank set temperature ... . 78 Temperature-guided circulation ..79 Activating a cooling function, example ..88 Time .
  • Page 107 Setting in expert mode Set temperature of the storage tank during Acquisition of the stored energy via the S solar charging ..... . . 84 09 probe .
