- Page 1 Operating and installation instructions REMKO KF 22 Cabled remote control For KWD 25-100 (EC) (Coanda), WLT 30-90 EC 338-2023-04 Edition 1, en_GB Read the instructions prior to performing any task!
- Page 2 Read these operating instructions carefully before commis- sioning / using this device! These instructions are an integral part of the system and must always be kept near or on the device. Subject to modifications; No liability accepted for errors or mis- prints! Translation of the original...
-
Page 3: Table Of Contents
Table of contents Safety and usage instructions......................4 1.1 General safety notes........................4 1.2 Identification of notes........................4 1.3 Personnel qualifications........................4 1.4 Dangers of failure to observe the safety notes................4 1.5 Safety-conscious working....................... 4 1.6 Safety notes for the operator......................5 1.7 Safety notes for installation, maintenance and inspection.............. -
Page 4: Safety And Usage Instructions
REMKO KF 22 Safety and usage instructions CAUTION! This combination of symbol and signal word 1.1 General safety notes warns of a potentially hazardous situation, which if not avoided may cause injury or mate- Carefully read the operating manual before com- rial and environmental damage. -
Page 5: Safety Notes For The Operator
"certificate of warranty" to conditions stipulated in this manual and comply REMKO GmbH & Co. KG at the time when the with all applicable regional regulations. units are purchased and commissioned. -
Page 6: Transport And Packaging
REMKO KF 22 1.11 Transport and packaging The devices are supplied in a sturdy shipping con- tainer. Please check the equipment immediately upon delivery and note any damage or missing parts on the delivery and inform the shipper and your contractual partner. For later complaints can not be guaranteed. -
Page 7: Technical Data
Technical data Unit data Series KF 22 Cabled remote control for KWD 25-100 EC Operating mode and WLT 30-90 EC Plug-in cable, length 5000 Operating range °C / r.H. +10 to +40 / 30 to 80, non-condensing Temperature range for storage °C / r.H. -
Page 8: Description
REMKO KF 22 Description Operation The cabled remote control is used for external operation of the indoor unit chiller. The cabled remote control must be mounted at the desired location at a height of approx. 1.60 m and a max. distance to the unit of 25 m. - Page 9 FAN key ON/OFF Press this key to set the desired fan speed. To switch the unit on or off, press the ON/OFF key. In the switched-on status: Up arrow Use this key to change the setpoint upwards. Operation is indicated by the symbols on the remote control display.
- Page 10 REMKO KF 22 Temperature FAN key The arrow up and arrow down keys allow the The ventilator speed can be adjusted by pressing desired target temperature to be set in 1 °C steps. the FAN key. It can be selected between Silent, This setting is not possible in recirculation mode.
- Page 11 Cooling mode Swing In cooling mode, the air in the room is cooled to Swing mode enables continuous, automatic louvre the set target temperature. Set the desired room adjustment. When switched on, the air inside the temperature by pressing the Up or Down arrow key room is distributed better.
-
Page 12: Assembly Instructions For Qualified Personnel
REMKO KF 22 Assembly instructions Installation for qualified personnel Route the four-wire plug cable between the installation location of the cabled remote con- Check the contents of the packaging for complete- trol and the switch box of the unit. If the 5 m... - Page 13 Connect the plug cable to the socket [A] of the Lock the housing front of the cabled remote cabled remote control. control in the mounting rear panel. There must be no mechanical stress on the circuit board. Route the plug cable and connect the plug in the LCON slot provided for this purpose on the unit board.
- Page 14 REMKO KF 22 Electrical drawings KF 22 for KWD 25 to 100 SM1 SM2 SM3 SM4 MODE °C Jp12 Jp11 Jp9 Jp10 Jp7 Jp8 M.H. KF 22 for KWD 25 to 100 (Coanda) K1 K2 MODE °C CON9...
- Page 15 Electrical drawings KF 22 for WLT 30 to 90 EC FAN 1 FAN 2 AUX 2 AUX 1 Auto ON/OFF 0-10V MODE °C...
-
Page 16: Commissioning
REMKO KF 22 Commissioning Switch the unit on using the cabled remote control. The cabled remote control is active. Check all key functions. The display of the cabled remote control changes accordingly. Mount all removed parts. Familiarise the operator with the functions. -
Page 17: Index
Index Assembly ......12 Safety Dangers of failure to observe the safety notes . - Page 18 REMKO KF 22...
- Page 20 REMKO QUALITY WITH SYSTEMS Air-Conditioning | Heating | New Energies Telephone +49 (0) 5232 606-0 REMKO GmbH & Co. KG Hotline within Germany +49 (0) 5232 606-0 Klima- und Wärmetechnik Telefax +49 (0) 5232 606-260 Im Seelenkamp 12 E-mail info@remko.de...
