REMKO Smart-Control Touch Safety and usage instructions CAUTION! This combination of symbol and signal word 1.1 General safety notes warns of a potentially hazardous situation, which if not avoided may cause injury or mate- Carefully read the operating manual before com- rial and environmental damage.
The setup, connection and operation of the plete and return the "certificate of warranty" to units and its components must be undertaken REMKO GmbH & Co. KG at the time when the in accordance with the usage and operating units are purchased and commissioned.
REMKO Smart-Control Touch 1.11 Transport and packaging The devices are supplied in a sturdy shipping con- tainer or inside the heat pump casing. Please check the equipment immediately upon delivery and note any damage or missing parts on the delivery and inform the shipper and your contrac- tual partner.
Technical data Series Smart Control Touch Operating mode Remote control / controller Power supply +12 V DC Enclosure class Power consumption < 100 Max. cable length Recommended cable 2 x 0.5 Dimensions Height Width Depth Environment Ambient temperature °C 0-70...
Information about assembly and installation can be found on the following pages of the operating manual. Information on operating the REMKO Smart Control Touch remote control can be found in the "REMKO Smart-Control Touch" operating manual. This remote control gives you options for setting and querying the relevant parameters of the REMKO heat pump at the user and expert levels.
Basic schema of the Smart Control Touch with WLAN connection and remote control Functions: Smart Control Touch connection of the heat pump to the customer’s WLAN router via WLAN and remote control with WLAN function in the WLAN network of the router.
Page 10
D: Remote control 3: 12V/GND connection to customer’s transformer Connection of the Smart Control Touch controller to a customer’s WLAN router via a LAN cable (patch cable) is done by connecting the internal WLAN stick. An Ethernet adapter is required for the connection.
Page 11
D: Remote control 3: 12V/GND connection to customer’s transformer Connection of the Smart Control Touch remote control to a customer’s WLAN router via a LAN cable (patch cable) is done via the RJ 45 interface. The WLAN stick must also be removed.
Page 12
Basic schema of the Smart Control regulation system with remote control and connection via LAN cable (patch cable) Functions: Smart Control Touch connection of the heat pump to the customer’s WLAN router via LAN cable (patch cable) and remote control with LAN cable (patch cable) connection.
Page 13
Basic schema of the Smart Control regulation system with remote control and connection via LAN cable (patch cable) Functions: Smart Control Touch connection of the heat pump to the customer’s router via LAN cable (patch cable) and remote control with LAN cable (patch cable) in conjunction with a customer’s switch.
Page 14
Note that the REMKO Smart-Control Touch only This is only possible at the expert level. To do so, supports the WPA 2 encryption/security standard. touch the REMKO logo in the upper right corner of For this purpose you must know the name of your the display.
You now have the option of controlling the relevant operating parameters for the user and expert level of your REMKO heat pump via a PC, laptop or smartphone. This function is available to you constantly whilst connected to the WLAN network of your own router.
Page 16
REMKO Smart-Control Touch Remove the four marked Phillips screws and Place the mounting plate together with the then pull the mounting plate together with the electronics in the surface-mounted housing electronics out of the surface-mounted and then screw it to the surface-mounted housing.
Page 17
Place the aluminium frame in front of the Flush-mounted installation mounting plate using the magnets. For the flush-mounted installation, a double socket with the following dimensions must be provided at the desired installation position. Fig. 2: Double socket A 12V direct current source is required for the flush-mounted installation.
Page 18
REMKO Smart-Control Touch The flush-mounted installation can be carried out Remove the four marked Phillips screws and as follows: then pull the mounting plate together with the electronics out of the surface-mounted Pull through the aluminium frame fixed by housing.
Page 19
Place the mounting plate together with the Place the aluminium frame in front of the electronics in the surface-mounted housing mounting plate using the magnets. and then screw it to the surface-mounted housing using the four marked Phillips screws. Plug the ribbon cable with the blue marking upwards into the terminal block at the back of the display and fix it with the grey lever.
