17. Configuration: As Built
Select Installation > As-Built Report to capture configuration and other site/
installation data for appending to a final commissioning report.
Refer to
18. Complete capture of commissioning data.
The link is now ready for use.

Configuration Changes to An Existing Installation

Where changes are to be made to an existing installation/configuration, follow the
configuration process relevant to the required change(s) in the preceding section,
Procedure Overview for a New Installation. However before doing so you may wish
to save the current configuration for subsequent restoration (rollback) in the event of
difficulties with the new configuration:
• Within Portal select File > Backup to save a current terminal configuration (as set
by the most recent Send action) to a user-selectable folder on your PC.
• Select File > Restore to prompt for selection of the saved configuration from your
PC, and its loading back into a terminal. Follow the on-screen prompts to complete
the restoration process.

Reports and Terminal Information

This section describes the Report screen and Information screen options.

About Reports

The Reports screen is under the Installation menu. It supports two reports, an
as-built report and a helpdesk data file. Both are for saving to a folder on your PC.
Refer to
As Built Report
• The file is in a user-accessible csv, Excel compatible format.
• Its purpose is to enable capture of configuration and other site/installation data for
appending to a final commissioning report.
• It would normally only be used on completion of an installation or reconfiguration.
However, if significant reconfiguration of an existing installation is to be conducted,
capturing before and after files can be of value for fault-finding purposes in the event
of a problem with reconfiguration.
• Report data is always current to the time of saving to your PC - no action is required
to put data into the report file.
Helpdesk Data File
260-668080-001 Rev 002 March 2013
Reports and Terminal Information on page 31
Reports and Terminal Information on page
Eclipse Edge User Manual
for details.
31.
31
