NOTE:
To return to the System Summary (previous) screen from other
screens, click on the <Back tab in the toolbar.

Portal Menus

The File menu supports standard file management commands plus:
• A 'New Portal' prompt, which brings up the Portal start-up screen for opening
concurrent sessions to other terminals.
• Configuration Backup and Restore.
• Backup saves the current terminal configuration (as set by the most recent Send
action) to a user-selectable folder on your PC.
• Restore prompts for selection of the saved configuration from your PC, and its
loading back into a terminal.
The Edit menu provides access to:
• Cut, copy, paste from/to appropriate fields within Portal screens, or from Portal to
an external document.
• Preferences supports customization of:
• Diagnostic safety timers default to last setting used (default is On).
• Hide configuration correction and warning messages - for current session
(default is Off).
• Ignore close confirmations (default is Off).]
• CSV preferences. Selections are provided for the character to be used as the
separator in CSV file exports. Options are comma, semi-colon, tab, or
user-defined.
The Installation menu provides access to:
• Licensing screen (Does not apply to Eclipse Edge).
• As-built report screen.
The Configuration menu provides access to:
• All configuration functions.
• Software maintenance.
• Security activation and de-activation.
All essential configuration data is captured in the on-board flash. For Eclipse Edge it
is factory installed. User access is not provided.
The Diagnostics menu provides access to:
• A system status summary, with system layout controls.
• System controls for protection locking, loopbacks, Tx muting, BER generation and
measurement.
• Event browser and history screens.
• Alarms status screen.
• Part-number screen.
