Figure 4-22.
6
Item
1
2
3
4
5
260-668080-001 Rev 002 March 2013
Software Management Screen
3
5
Description
Software Status shows the active version for each load destination, and
any current load activity.
Shows the active software versions (ODU and Control Module).
Select an action option for software transfer and/or activate. Information
displayed with the software transfer and/or activate options is context
sensitive.
The Select button opens a browser on your PC to locate and select software
to load.
To select the software rollback option click the Advanced button.
1
2
4
