Chapter 4. Eclipse Edge Configuration and Diagnostics
Viewing other Portal screens does not affect the aggregation of performance
statistics.
The Stop button terminates the data aggregation, but leaves for viewing the data
collected / displayed to that point.
The Clear button clears all data.
If the terminal is powered off or reset during data capture, a warning is displayed
advising that collected data has been interrupted.
Table 4-10
Table 4-10.
Statistic
In Ucast Pkts
In Broadcast Pkts
In Multicast Pkts
HC In Octets
In Discards
Out UCast Pkts
Out Broadcast Pkts
Out Multicast Pkts
HC Out Octets
Dot3 In Pause
Frames
100
describes each statistic for the DAC ES module in the IDUspe.
Description of DAC ES RMON Performance Statistics
Description
The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were not addressed to a multicast
or broadcast address at this sub-layer.
The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a broadcast
address at this sub-layer.
The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a multicast
address at this sub-layer. For a MAC layer protocol, this
includes both Group and Functional addresses.
The total number of octets received on the interface,
including framing characters. This object is a 64-bit version
of If In Octets.
The number of inbound packets which were chosen to be
discarded even though no errors had been detected to
prevent them being deliverable to a higher-layer protocol.
One possible reason for discarding such a packet could be
to free up buffer space.
The total number of packets that higher-level protocols
requested be transmitted, and which were not addressed to
a multicast or broadcast address at this sub-layer, including
those that were discarded or not sent.
The total number of packets that higher-level protocols
requested be transmitted, and which were addressed to a
broadcast address at this sub-layer, including those that
were discarded or not sent.
The total number of packets that higher-level protocols
requested be transmitted, and which were addressed to a
multicast address at this sub-layer, including those that
were discarded or not sent. For a MAC layer protocol, this
includes both Group and Functional addresses.
The total number of octets transmitted out of the interface,
including framing characters. This object is a 64-bit version
of If Out Octets.
Number of valid pause frames received.
