Chapter 4. Eclipse Edge Configuration and Diagnostics
• Synchronization with an external Simple Network Time Protocol (SNTP) server.
SNTP is a reduced accuracy version of NTP. The protocol fields are the same, but the
data values and algorithms used have reduced accuracy so that it can be
implemented on limited capacity systems.
Refer to
Figure 4-21.
2
Item
1
2
3
4
5
SNTP Operation supports connection to one or more external SNTP time servers
via the NMS network.
• The server is identified by its IP address. When first configuring the time server
option, the Synchronize Now button should be used, which will immediately reset
the terminal time to the server time.
• Thereafter the built-in SNTP client automatically establishes connection to the time
server each hour.
72
Figure 4-21.
Date/Time Screen
1
3
Description
Current date and time.
Click to select SNTP time synchronization. Enables synchronization to an
external SNTP server - timing is continuously maintained by the server, or
servers.
SNTP configuration panel. Servers are added and their status (active or
inactive) confirmed.
Click to open Change Time editing.
A date time can be direct-entered, or set from the Portal PC clock.
Subsequent timing is maintained by the internal terminal clock.
4
5
