lower right corner of your PC screen.
Or, from the Control Panel of your PC, select Network and Dial-up
Connections > Local Area Connection.
The Local Area Connection Status window is displayed.
2. Click Properties.
3. Select Internet Protocol (TCP/IP).
4. Ensure its associated box is ticked.
5. Click
The Internet Protocol (TCP/IP) Properties window is displayed.
NOTE:
Before making any change to the settings in this window, record and
retain the existing settings, which may pertain to your company
LAN.
6. Select Obtain IP Address Automatically and Obtain DNS Server Address
Automatically, as shown in the window above.
7. Click OK, then OK again to confirm the settings, and exit.

Setting Up A TCP/IP Ethernet Portal Connection

NOTE:
TCP/IP connection requires knowledge of the IP address of the radio
you are connected to. Your PC operates as a device on the NMS LAN
of the physically connected radio. As each radio has its own NMS
router with a unique IP address, TCP/IP settings on your PC must be
changed each time you physically connect to a different Eclipse
260-668080-001 Rev 002 March 2013
LAN Icon
Properties.
