• ODUspe is designed to deliver standard power performance, as described in the table
below. For more detailed information, refer to the Eclipse Edge datasheet.
Table 2-1.
Freq Band
GHz
7
13
15
18
23

Protected Operation for Edge

Eclipse Edge supports dual-ODU hot standby or space diversity link configurations
between IDUspe 16x terminals.
Where two ODUs are to be connected to a single antenna for hot-standby
configurations, a direct-mounting coupler is used. They are available for equal or
unequal loss operation. Equal loss is nominally 3.5/3.5 dB. Unequal is nominally 1.5/
6.5 dB.
• Protected links can only be configured between Edge IDUs.
• One IDUspe is used at each end of the link to connect to the main ODUspe and
standby ODUspe.
• The IDUspe incorporates duplicated modems and PoE injectors for maximum
reliability.
Figure 2-4.
260-668080-001 Rev 002 March 2013
ODUspe Tx Power, Rx Threshold
Tx Pwr
Output
4 Mbit/s
dBm
2xE1
24 -92
20 -92
20 -92
19 -91
19 -91
Eclipse Edge 1+1 Hot-Standby Link (IDU-IDU)
Eclipse Edge User Manual
Receiver Threshold dBm
8 Mbit/s 16 Mbit/s
4xE1 8xE1
-90 -87
-90 -87
-90 -87
-89 -86
-89 -86
32 Mbit/s
16xE1
-83
-83
-83
-82
-82
