Portal User Logged On
User logged on to the terminal.
POST Failed
Power on self test did not complete without errors. The log entry identifies the failed
test.
Power On
The radio has completed a power on reset. Note that this entry could be replaced by
the standard cold start trap.
Protection Switch
Protection switch has occurred. The log entry will include details of the reason for the
switch. Applies to RAC and DAC protection.
Protection Switch Failure
A required protection switch was unable to occur. The log entry will include details of
the reason for the failure.
Reset Button Pressed
The reset button has been pressed for this device, and it will be reset.
Rx Performance Monitoring Reset
The Rx performance monitoring values for RSSI maximum and minimum have been
reset.
Set Power Out of Range
The Tx power set was above the maximum power or below the minimum power
capabilities.
Software Changed
The software version being used by the terminal has been changed. The log entry
includes the new and the previous software version.
Software File Received
A file has been received by the terminal. The log entry includes the file name and size.
Software Reset
Software has been reset by Portal or SNMP.
