User Hints
• Data that you can change is lettered in solid color. Non-configurable data is greyed
out.
• Many on-screen items (attributes/labels/features) are supported by ToolTips. A
ToolTip can be viewed by slowly moving the mouse pointer over an item.
• Use the maximize button in the top right corner of a window to go to a full screen.
Click again to restore down. Or resize by clicking and dragging a corner of the
window.
• Portal screens can be dragged and resized.
• Portal memorizes the most recent screen size/position settings for future use.
Table 4-1.
Icon
260-668080-001 Rev 002 March 2013
Description
Menu bar. Provides direct navigation to main areas of user interest.
Clicking on a Menu brings up a sub-menu that provides direct access to
relevant screens and commands.
For information on menu bar menus, refer to
Tool bar. Provides quick access to common actions. It includes direct
access to the System Summary screen, which provides an overview of the
configured terminal and its status. The System Summary screen is the
Portal opening screen.
Status bar. Shows the site name, terminal name and its IP address, plus
problem graphics and a system alarm/severity icon, which provides an
overall status summary for the terminal. The color of the icon reflects
alarm/problem severity. See
For an Ethernet connection, the IP address displayed is the Ethernet
address of the terminal.
System Alarm Severity Colors
Severity
Warning
Minor
Major
Critical
No alarms
