Edge Reset Options
Two reset options are provided for Eclipse Edge. Refer to:
• Software Reset for Edge
• Factory Reset for Edge
Software Reset for Edge
A software reset is equivalent to a power-down reboot (power off - pause - power on),
with one important difference; a copy of the Helpdesk Data File is automatically
saved to a default folder on your Portal PC at C:\Program Files\Portal\Reset Logs\.
For information on the software reset function, refer to
page 115.
Factory Reset for Edge
A factory reset is supported on the IDUspe using its IP Reset recessed front-panel
switch. The switch initially enables a temporary DHCP server, and after an extended
hold-down, the factory reset.
The reset sets the IDU back to factory defaults, which for the IDUspe are:
• IP address: 169.254.1.1
• Netmask:255.255.0.0
• DHCP:Enabled with an address range of 169.254.2.1 to 169.254.254.255 and a
netmask of 255.255.0.0
• Routes:No configured routes, RIP and OSPF disabled.
• Configuration:Any/all link or trib configuration parameters erased.
See IP Reset Function.
IP Reset Function
Table 2-3
Table 2-3.
Switch Action
Press and hold for 0
to 5 seconds.
Release before 5
seconds.
Press and hold down
from 5 to 10
seconds.
260-668080-001 Rev 002 March 2013
describes the function and operation of the IP Reset button on the IDUspe.
Action of IDUspe IP Reset Switch
LEDs
IDU and ODU status LEDs
go off (unlit).
LEDs revert to their
original state (Indication
prior to switch release).
IDU and ODU status LEDs
go solid orange.
Eclipse Edge User Manual
Advanced Management on
IDU Response
None. No affect on IDU/link
operation.
None.
None.
