AILERON PUSHROD INSTALLATION.

Aileron pushrods assembly follow pictures
below.
Pushrod L= 114mm.
M lock
3
Metal Levis.
Center the servo using the radio system.
Loctite secure.
Repeat the procedure for other aileron.
www.seagullmodels.com
covering from over the two main gear mount-
ing slots located in the bottom of the wing.
wire and support mounting block into the pre-
drilled hole in one mounting slot.

INSTALLING THE MAIN GEAR WIRES.

3 x 15mm.
Support
mounting block.
1) Using a modeling knife, remove the
2) Insert the 90º bend of one main gear
Pen.
Remove
covering.
