Wing Assembly - Seagull Models SPARROW HAWK 1.6-2.0 Assembly Manual

3x15mm.
Be careful do not to drill through the
top of the wing!
Glue.
Machine screw 3 x 15mm.
www.seagullmodels.com
NOTE: We highly recommend using 30
minute epoxy as it is stronger and provides
more working time, allowing the builder to
properly align the parts. Using fast cure epoxy
when joining the wing halves could result in the
glue drying before the wing halves are aligned
properly which may result in failure of the wing
centre section during flight.
The brace should slide in easily up to the
centreline that you drew.If not, use 220 grit
sandpaper with a sanding block and sand
down the edges and ends of the brace until it
fits properly.
its fit ineach wing half. Coat both sides of one
half of the dihedral brace with 30 minute epoxy.
Next, pour some epoxy into the dihedral box in
one wing panel. Make sure you cover the top
and bottom as well as the sides of the dihedral
brace. Use enough epoxy to fill any gaps.
Glue.

WING ASSEMBLY.

1) Test fit the wing tube into each wing half.
Masking tape.
Epoxy.
2) Remove the brace when satisfied with
13
