KIT CONTENTS

This section contains a list of the components that are included in the SmarTrax kit. Before beginning the SmarTrax
installation, compare the items in the kit with the components on this list. If you have questions about the kit,
contact your Raven dealer.
NOTE: The SmarTrax node (P/N 063-0173-228) is sold separately. Contact your local Raven dealer for
ordering information.
TABLE 1. SmarTrax Installation Kit (P/N 117-5032-037)
Not Pictured
Not Pictured
Manual No. 016-5032-037 Rev. A
Item Description
Manual - SmarTrax Calibration &
Operation
SmarTrax, Case IH Patriot 2250, Non-Steer
Ready, MY17 and Newer Installation
Manual
Valve - SmarTrax Hydraulic
Switch - Flow
Bracket - Hydraulic Valve Mounting
Bracket - Node Mounting
Cable - Hydraulic Valve Harness
Cable - Node Harness
INTRODUCTION
Part Number Qty.
016-0171-277
016-5032-037
334-0003-088
334-0003-085
107-0171-705
107-0172-084
115-4001-111
115-4001-135
1
1
1
1
1
1
1
1
9
