I NTRODUCTION

CHAPTER

C H A P T E R 2

This manual applies to the following machines:

MAKE: Case IH

MODEL: Patriot 2250 MY17 and Newer

FIGURE 1. Case IH Patriot 2250

Before installing the SmarTrax system, park the machine where the ground is level, clean, and dry. Turn off the

machine and leave it turned off for the duration of the installation process. Bleed pressure from the hydraulic

system by loosening the hydraulic fittings slowly, where applicable.

During the installation process, follow good safety practices. Be sure to carefully read the instructions in this

manual as you complete the installation process.

Raven Industries recommends the following best practices when installing or operating the SmarTrax system for

the first time, at the start of the season, or when moving the SmarTrax system to another machine:

Manual No. 016-5032-037 Rev. A
