SYSTEM SETTINGS

System Setting
Line Acquisition (LA)
Aggressiveness
OnLine (OL) Sensitivity
System Setting
Zero Yaw
Message Frequency - GGA
and VTG
Message Frequency - ZDA
HDOP
P/N 016-9001-022 Rev. D
Average Suggested
Setting Range
10 4 to 16
10 4 to 20
Average Acceptable
Setting Range
0 -2 to 2
10 Hz 10 Hz
.3 Hz .3 to 10 Hz
2.5 N/A
Function
The LA Aggressiveness value affects how
quickly the machine steers toward a displayed
guidance line when it is traveling further than
24 inches [60 cm] from the desired path.
The OL Sensitivity value affects the response of
the machine while steering within 24 inches [60
cm] of the displayed guidance line.
Function
Indicates amount error in the internal yaw
sensor while no yaw motion is present.
Displays the frequency of GGA messages from
the GPS receiver.
Displays the frequency of GGA messages from
the GPS receiver.
Indicates the quality of the GPS signal.
VIPER 4
39
