- Page 1 SmarTrax™ Installation Manual Ag-Chem Rogator 864, 874, 1064, 1064C, 1074, 1264, 1264C, 1274, 1274C, SS...
- Page 2 GPS satellites, the OmniSTAR correction service or the WAAS correction service. Raven Industries accepts no responsibility for the use of the signal for other than the stated purpose. Raven Industries shall not be responsible or liable for incidental or consequential damages or a loss of anticipated benefits or profits, work stoppage or loss or impairment of data arising out of the use, or inability to use, the SmarTrax or any of its components.
- Page 3 Manual # 016-0190-031 H A P T E R NTRODUCTION Congratulations on your purchase of the Raven SmarTrax system! This system is designed to provide cutting-edge, hands-free steering of your machine via GPS coordinates.
-
Page 4: Basic Kit
Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual Below you will see the kit contents that you should have received with this SmarTrax kit. Basic Kit Contents Ag Chem Rogator 64/74/SS Series SmarTrax Kit Contents Quantity Item Description Part Number... - Page 5 Caution must be exercised. Any work carried out on the hydraulic system must be performed in accordance with the machine manufacturerer’s approved maintenance instructions. Raven Industries recommends that appropri- ate protective equipment be worn when working on the hydraulic system. Ob- jects or materials that are able to bypass the machine’s hydraulic filtration system...
- Page 6 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual Contacting We welcome your feedback about this manual. If you have any comments or suggestions for improvement, please let us know by contacting our Customer Raven Support Center by any of the following methods:...
- Page 7 Manual # 016-0190-031 H A P T E R OUNTING THE NIVERSAL RACKET AND ALVE The mounting location of the Steering Assist Valve Bank and Mounting Installing the Bracket is on the cross member of the machine, just below the cab. Universal (See figure below) Bracket on...
- Page 8 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual Installing the The mounting location of the Steering Assist Valve Bank and Mounting Bracket is on one of the cross members underneath the cab adjacent to Universal the access ladder. Bracket on Only the valve mount bracket will be used in this installation.
-
Page 9: Steering Control Unit
Manual # 016-0190-031 H A P T E R YDRAULICS Accessing the The Ag-Chem RoGator Steering control Unit (SCU) is located in front of the cab. Steering NOTE: Be sure the tractor is turned off and all pressure has Control Unit been relieved from the tractor’s hydraulic system by turning the steering wheel left then right. - Page 10 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual All new hoses will be routed on the inside of the left frame rail back to the Steering Assist Valve. There may be additional fittings that are not used. These fittings are to accomodate for model year changes.
- Page 11 Manual # 016-0190-031 Disconnecting Label original T and P hoses and their corresponding ports on the SCU. T and P Ports T Port Original P Port T Hose Original P Hose T and P Ports on the SCU, Original T and P Hoses Disconnect the original Tank hose from the Tank port.
- Page 12 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual Disconnecting Label original L and R hoses and the corresponding ports on the SCU. L and R Ports L Port Original R Port L Hose Original R Hose L and R Ports on the SCU, Original L and R Hoses Disconnect the Right hose from the Right port.
-
Page 13: Priority Valve
LS-PV Valve. Hose to the Priority Valve Priority Valve LS-PV hose LS-PV port to Prior- ity Valve Connecting the LS-PV hose to the Priority Valve Connect other end of the hose to the LS-PV Port on the SmarTrax Valve. - Page 14 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual Connecting T, Connect the supplied T and P hoses (P/N 214-1000-219) to the branch ends of the respective tee connectors. P, L, R and LS Hoses to the T Hose P Hose...
- Page 15 Connect the supplied L and R hose to A Port and B Port respectively. Valve Secure the hoses into place with cable ties. Replace any guard or plates used to protect the SCU. Attach pressure switch to the PS Port on the SmarTrax valve.
- Page 16 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual...
-
Page 17: Installation
ENSOR Mounting the Yaw Sensor Yaw Sensor Installing the Raven Yaw Sensor is quick and easy. Raven recommends that you keep the following points in mind while installing the sensor: Installation • The sensor is not weatherproof. Mount the sensor inside of the machine’s cab or drivers compartment. - Page 18 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual Installation 1 Mount the Yaw Sensor to the floor inside of the vehicle’s cab using the double sided tape on the sensor or steel bolts or screws through the mounting plate. See the Mounting the Yaw Sensor section above for mounting location considerations.
-
Page 19: Start-Up Procedures
Manual # 016-0190-031 H A P T E R TART- ROCEDURES After installing the SmarTrax on your machine, always follow these start-up pro- cedures. Turn the wheels fully from side to side numerous times to remove air from the hydraulic system. - Page 20 Ag Chem Rogator 64/74/SS Series SmarTrax Installation Manual Notes:...
- Page 23 How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
- Page 24 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
