3
EXTERNE ANSCHLÜSSE
3.1 Anschlüsse im Kabelfach unter der Kabelabdeckung
Anschlussbelegung
Stromversorgung
1 x SMA (optional)
1 x RSMA (optional)
USB0, USB1, USB2, USB3
RJ45
COM1, COM2
48
12/24/48 VDC nominal
Externe WWAN-Antenne
Externe WLAN-Antenne
USB 2.0 Schnittstellen (HI-SPEED™), bootfähig
LAN Ethernet 10/100/1000 MBit/s
Serielle Schnittstellen
