NOTES ON THE ELECTRICAL INSTALLATION

Technical data:

− Integrated, galvanically separated direct current power supply unit

− 12/24/48 VDC nominal (wide-range power supply unit)

− 60 W / 80 W internal

− Voltage range 9 to 60 VDC

6.2 Fuses

NOTICE: Property damage

Fit fuses to the following supply lines:

− The DC+ connecting cable must be protected by a fuse (max. 30 AT).

− The ignition connecting cable must be protected by a fuse of the following type:

5x20 mm T 125 mA L / 250 V, for example Wickmann 195-125 mA / 250 V.
